Vishay BFC233660223 Interference Suppression Capacitor
The MKP336 6 Y2 is an interference suppression film capacitor designed for EMI filtering between line and ground in industrial applications. It features a polypropylene dielectric with metallized film electrodes, encased in a flame-retardant epoxy resin sealed plastic case. Rated for 300 Vac AC and 1000 VDC, with a maximum temperature of 105°C, it is suitable for frequencies up to 60 Hz and RoHS compliant. Available in various lead pitches (10 mm, 15 mm, 18 mm) and packaging options like loose in box or taped reel, ensuring reliable mounting on printed-circuit boards withstanding vibration, shock, and thermal cycling.
Vishay BFC233660223 Interference Suppression Capacitor Specifications:
- Rated AC voltage: 300 Vac at 50/60 Hz
- Permissible DC voltage: 1000 V
- Maximum temperature: 105°C
- Dielectric: Polypropylene film
- Electrodes: Metallized film
- Encapsulation: Flame-retardant epoxy resin, UL 94 V-0
- Lead pitch options: 10 mm, 15 mm, 18 mm
- Lead configuration: Loose or taped on reel
- Climatic testing: Class 35/105/56/8 (EN60068-1)
- Certifications: RoHS, IEC 60384-14, UL 60384-14, ENEC
- Dimensions: Vary depending on configuration, with specific measurements provided
- Ingress protection: Sealed in epoxy resin for mechanical stability
Buy the Vishay MKP336 6 Y2 – Reliable Interference Suppression Film Capacitors for Industrial Applications
Enhance your electromagnetic interference filtering with the Vishay MKP336 6 Y2, a high-quality film capacitor rated for 300 Vac and 105°C. Designed for EMI suppression between line and ground, it features polypropylene dielectric and metallized film electrodes, ensuring excellent voltage stability and durability. Available in various lead pitches and packaging options like loose in box or taped reel, it is ideal for mounting on printed-circuit boards in industrial and RoHS-compliant applications. Order online today for reliable performance and compliance assurance.
Buy Vishay MKP336 6 Y2 now and experience unmatched EMI filtering reliability and performance in industrial environments.
