Vishay BFC233841154 Interference Suppression Capacitor
The MKP338 4 X2 is a high-quality interference suppression film capacitor designed for across-the-line applications. Rated at 300 Vac with a temperature range of -55°C to +105°C, it features polypropylene dielectric and metallized film electrodes for reliability and self-healing properties. Suitable for EMC filtering and interference suppression in power supplies, it meets IEC 60384-14 standards, features UL and CSA approvals, and has various lead pitch options for flexible mounting. Its flame-retardant epoxy resin sealed plastic case ensures safety and durability in industrial settings.
Vishay BFC233841154 Interference Suppression Capacitor Specifications:
- Rated voltage: 300 Vac
- Temperature range: -55°C to +105°C
- Dielectric: Polypropylene film
- Electrodes: Metallized film
- Construction: Mono
- Encapsulation: Plastic case, epoxy resin sealed, flame retardant UL-class 94 V-0
- Lead pitch options: 15 mm, 22.5 mm, 27.5 mm, 37.5 mm, 55 mm
- Lead length: Options from 3.5 mm to 25 mm
- Capacitance range: 0.01 UF to 10 UF
- Capacitance tolerance: +20%, +10%
- Climatic class: 55/105/56 according to IEC 60068-1
- Standards: IEC 60384-14, EN60384-14, UL 60384-14
- RoHS compliant and self-healing properties
- Certifications: UL Listed, CSA Certified, EN EC 60384-14
- Maximum application temperature: 105°C
- Permissible DC voltage: 800 V at 85°C, 630 V at 110°C
Buy the Buy Vishay MKP338 4 X2 Part Number BFC233841154 Online
Enhance your power filtering with the Vishay MKP338 4 X2 interference suppression capacitor, rated at 300 Vac and up to 105°C. Its polypropylene dielectric and metallized film electrodes ensure high reliability, self-healing properties, and compliance with IEC and UL standards. Suitable for EMC filtering in across-the-line power applications, this capacitor features various lead pitches for versatile mounting options. Its flame-retardant epoxy case guarantees safety and durability, making it an ideal choice for industrial and electronic power equipment requiring effective interference suppression.
Buy Vishay MKP338 4 X2 now and experience unmatched reliability and interference suppression performance for power line applications.
Frequently Asked Questions
Where can I buy Vishay BFC233841154?
You can click on the BUY or RFQ button to purchase BFC233841154 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part BFC233841154?
You can download the BFC233841154 datasheet or visit the Vishay website for support.
Who is the manufacturer of BFC233841154?
Vishay
