Vishay CRCW0402470RFKEDHP Thick Film Chip Resistor
The Vishay CRCW-HP e3 series represents a robust solution for power measurement electronics requiring reliability, stability, high power ratings, and excellent pulse load performance. These thick film chip resistors are AEC-Q200 qualified and feature a double-side printed resistive element. Typical applications include battery management systems in automotive appliances. The resistors offer excellent pulse load capability and enhanced power ratings, ensuring consistent performance under demanding conditions. They are available in various sizes and tolerances to meet diverse application requirements.
Vishay CRCW0402470RFKEDHP Thick Film Chip Resistor Specifications:
- description: Pulse proof, high power thick film chip resistors
- resistance_range: 1 Ω to 1 M Ω (jumper 0 Ω)
- resistance_tolerance: ± 5 %, ± 1 %, ± 0.5 %
- temperature_coefficient: ± 200 ppm/K, ± 100 ppm/K
- rated_dissipation_p_70_1: 0.2 W (for 0402), 0.25 W (for 0603), 0.5 W (for 0805), 0.75 W (for 1206), 1.5 W (for 1218), 1.0 W (for 2010), 1.5 W (for 2512)
- operating_voltage_u_max_acrms_dc: 50 V (for 0402), 75 V (for 0603), 150 V (for 0805), 200 V (for 1206, 1210, 1218), 400 V (for 2010), 500 V (for 2512)
- permissible_film_temperature_f_max_1: 155 °C
- operating_temperature_range: -55 °C to +155 °C
- max_resistance_change_at_p_70: ≤ 2.0 % after 1000 h, ≤ 4.0 % after 8000 h
- permissible_voltage_against_ambient_insulation: 75 V (for 0402), 100 V (for 0603), 200 V (for 0805, 1206, 1210, 1218), 300 V (for 2010, 2512)
- marking: See document “Surface Mount Resistor Marking”
- packaging_code_ed_et7: 10 000/50 000
- packaging_style: Paper tape acc. to IEC 60286-3, Type 1a
- packaging_width: 8 mm
- packaging_pitch: 2 mm
Buy the CRCW0402470RFKEDHP VISHAY Thick Film Chip Resistor | myMectronic
Purchase the Vishay CRCW0402470RFKEDHP Thick Film Chip Resistor securely and conveniently online.
Buy Now
Frequently Asked Questions
Where can I buy Vishay CRCW0402470RFKEDHP?
You can click on the BUY or RFQ button to purchase CRCW0402470RFKEDHP from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part CRCW0402470RFKEDHP?
You can download the CRCW0402470RFKEDHP datasheet or visit the Vishay website for support.
Who is the manufacturer of CRCW0402470RFKEDHP?
Vishay
