Vishay F222K47S3NN63J7R Ceramic Disc Capacitor
The product is a ceramic disc capacitor designed for high reliability, low losses, and high capacitance in a small size, suitable for electronic circuits such as SMPS, HF ballast, and high voltage applications. It features kinked leads, material compliant with UL 94 V-0, and is available in various voltage ratings up to 3 kV and capacitance from 100 pF to 4700 pF. The dielectric types include SN Y5R, and YS5R, with operating temperatures from -30°C to +125°C, and a dissipation factor of 0.2 %. Encapsulated in epoxy resin, it meets IEC standards and is RoHS compliant.
Vishay F222K47S3NN63J7R Ceramic Disc Capacitor Specifications:
- Capacitance range: 100 pF to 4700 pF
- Rated voltage: up to 3 kV
- Dielectric types: SN Y5R, YS5R
- Operating temperature: -30°C to +125°C
- Dissipation factor: 0.2 % max.
- Insulation resistance at 500 V: 210000 MΩ min.
- Lead diameter: 0.6 mm
- Lead spacing: 5 mm or 7.5 mm
- Encapsulation: epoxy resin, flame resistant UL 94 V-0
- Marking includes capacitance value, tolerance (+10 %, +20 %), voltage
- Dimensions vary, disc size < 6.5 mm or 7.5 mm with lead spacings of 5 mm or 7.5 mm
- Maximum operating temperature: +125°C
- Compliance: RoHS, IEC 60384-9, EIA 198
Buy the Vishay Series F Ceramic Disc Capacitor: F222K47S3NN63J7R
Purchase the Vishay ceramic disc capacitor F222K47S3NN63J7R online today to ensure your electronic project benefits from high reliability, low losses, and compact design. Suitable for high-voltage applications up to 3 kV, with a capacitance of 4700 pF and operating temperature range from -30°C to +125°C, this capacitor guarantees excellent performance. Its epoxy resin encapsulation provides durability, while kinked leads facilitate easy soldering. Order now and secure a dependable component for your high-voltage, low-loss electronic circuits with fast shipping and hassle-free online purchasing.
Buy Vishay F222K47S3NN63J7R now and experience unmatched reliability and performance in high-voltage electronic circuits.
Frequently Asked Questions
Where can I buy Vishay F222K47S3NN63J7R?
You can click on the BUY or RFQ button to purchase F222K47S3NN63J7R from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part F222K47S3NN63J7R?
You can download the F222K47S3NN63J7R datasheet or visit the Vishay website for support.
Who is the manufacturer of F222K47S3NN63J7R?
Vishay
