Vishay F222K75S3NR83K0R Ceramic Disc Capacitor
The F222K75S3NR83K0R capacitor is a high-reliability ceramic disc component suitable for low loss, high capacitance applications such as SMPS, HF ballast, and snubber circuits. It features a Class 2 dielectric with Y5R material, voltage ratings up to 3 kV, and capacitance from 100 pF to 4700 pF. The capacitor is designed with kinked leads and epoxy resin encapsulation that meets UL 94 V-0 flammability standards. Operating temperature range is -30°C to +125°C, with low dissipation factor of 0.2%, high insulation resistance, and precise marking indicating capacitance and voltage ratings.
Vishay F222K75S3NR83K0R Ceramic Disc Capacitor Specifications:
- Capacitance range: 100 pF to 4700 pF
- Voltage ratings: 500 V, 1 kV, 2 kV, 3 kV
- Dielectric: Y5R ceramic material, Class 2
- Temperature range: -30°C to +125°C
- Dissipation factor: Max 0.2%
- Insulation resistance: Min 210000 MΩ at 500 V
- Lead diameter: 0.6 mm
- Lead spacing: 5 mm or 7.5 mm
- Encapsulation: epoxy resin, UL 94 V-0 rated
- Marking: capacitance and voltage in accordance with EIA standards
- Operating temperature: -30°C to +125°C
- Application: snubber, high voltage circuits, HF ballast, SMPS
Buy the VISHAY F222K75S3NR83K0R – Reliable Ceramic Disc Capacitor for Industrial Applications
Order the Vishay ceramic disc capacitor F222K75S3NR83K0R today to secure a high-quality component with low losses, high capacitance, and robust design. Ideal for industrial applications requiring high voltage tolerance, low dissipation factor, and excellent thermal stability. Easily integrated into snubber circuits, power electronics, and high-voltage systems. Take advantage of fast shipping and secure online purchasing options for this reliable and durable component, ensuring your project’s success and longevity.
Buy Vishay F222K75S3NR83K0R now and experience unmatched reliability and performance in your high-voltage electronic circuits.
Frequently Asked Questions
Where can I buy Vishay F222K75S3NR83K0R?
You can click on the BUY or RFQ button to purchase F222K75S3NR83K0R from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part F222K75S3NR83K0R?
You can download the F222K75S3NR83K0R datasheet or visit the Vishay website for support.
Who is the manufacturer of F222K75S3NR83K0R?
Vishay
