Vishay F339X131548KFI2B0 EMI Suppression Capacitor
High-performance interference suppression film capacitor designed for X1 applications, rated at 480VAC with a polypropylene dielectric, metallized electrodes, and sealed in a flame retardant epoxy resin case. Suitable for 3-phase and across-the-line connections, its robust construction provides stability under severe ambient conditions, including high humidity and temperature up to 110°C. Ideal for electromagnetic interference suppression in industrial power systems, ensuring compliance with safety standards such as IEC, UL, and CSA. Features a wide capacitance range and multiple mounting options for PCB integration and reliable operation in demanding environments.
Vishay F339X131548KFI2B0 EMI Suppression Capacitor Specifications:
- Rated AC voltage: 480V
- Permissible DC voltage: 1000V
- Capacitance range: 0.001 pF to 1.0 HF
- Capacitance tolerance: ±20 %, +10 %, or ±5 % (on request)
- Dielectric: Polypropylene film
- Electrodes: Metallized
- Construction: Series, seal in flame-retardant epoxy resin
- Maximum application temperature: 110°C
- Impedance: as per frequency curve (typical)
- Insulation resistance: >50 % of rated voltage at 23°C
- Certifications: IEC 60384-14, UL, CSA, ENEC
- Lead pitch options: 10mm, 15mm, 22.5mm, 27.5mm
- Mounting: Screw or PCB mount in various configurations
- Vibration & shock: Compliant with IEC standards
- RoHS compliant
- Sealed and flame retardant case
Buy the Vishay Series EMI Suppression Capacitor 480VAC Part Number F339X131548KFI2B0
Purchase the Vishay F339X1 EMI suppression capacitor online today and ensure your industrial power systems meet stringent EMI standards. Designed for robust, reliable performance in severe ambient conditions, this 480VAC capacitor is ideal for 3-phase and across-the-line applications. Its polypropylene dielectric and series construction provide excellent stability, while various mounting options allow easy PCB integration. Order now for fast delivery and ensure your electrical systems operate safely and efficiently with Vishay’s trusted component for interference suppression in demanding industrial settings.
Get Vishay F339X1 today—built for electromagnetic interference suppression and high stability in demanding industrial environments.
Frequently Asked Questions
Where can I buy Vishay F339X131548KFI2B0?
You can click on the BUY or RFQ button to purchase F339X131548KFI2B0 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part F339X131548KFI2B0?
You can download the F339X131548KFI2B0 datasheet or visit the Vishay website for support.
Who is the manufacturer of F339X131548KFI2B0?
Vishay
