Vishay F339X151048KKI2B0 Interference Suppression Capacitor
The F339X1 480VAC interference suppression film capacitor is designed for 3-phase and across-the-line applications, particularly in environments demanding high stability. Constructed with metallized polypropylene dielectric and flame-retardant epoxy resin sealing, it offers reliable performance in severe ambient conditions. Suitable for suppressing electromagnetic interference and handling high humidity, it withstands voltages up to 480V AC and temperatures up to 110°C. Its robust design makes it ideal for series impedance and noise filtering in industrial automation and power systems.
Vishay F339X151048KKI2B0 Interference Suppression Capacitor Specifications:
- Rated AC Voltage: 480V
- Dielectric: Polypropylene film
- Construction: Metallized series, flame-retardant epoxy sealing
- Maximum Temperature: 110°C
- Capacitance Range: 0.001 pF to 1.0 HF (preferred values according to E6)
- Capacitance Tolerance: ±20%, +10%, or on request ±5%
- Lead Pitch: 10 mm to 27.5 mm
- Lead Material: Tinned wire
- Permissible DC Voltage: 1000V
- Climatic Testing: IEC 60068-1 55/110/56/B
- Standards: IEC 60384-14, EN 60384-14, UL 60384-14, CSA-E384-14
- Certifications: UL, CSA, ENEC, CB-Test
- Encapsulation: UL V-0 flame-retardant epoxy resin
- Dimensions: Length and width vary; typical range around 15 mm to 50 mm depending on capacitance
Buy the Vishay Series X1 Interference Suppression Capacitor: F339X1
Purchase the Vishay F339X1 480VAC interference suppression capacitor online today and ensure your power systems operate with minimal electromagnetic interference. Designed for industrial use, this high-voltage film capacitor withstands temperatures up to 110°C and provides stable performance in severe ambient conditions. Its flame-retardant epoxy sealing offers added safety. Ideal for 3-phase and across-the-line applications, it effectively reduces noise, supports series impedance operations, and meets international safety standards. Trust Vishay quality for your filtration needs and improve power quality quickly and reliably.
Get Vishay F339X1 480VAC interference suppression capacitor today—built for reliability in industrial power filtering and noise reduction.
Frequently Asked Questions
Where can I buy Vishay F339X151048KKI2B0?
You can click on the BUY or RFQ button to purchase F339X151048KKI2B0 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part F339X151048KKI2B0?
You can download the F339X151048KKI2B0 datasheet or visit the Vishay website for support.
Who is the manufacturer of F339X151048KKI2B0?
Vishay
