Vishay IHLP2525EZER2R2M01 Power Inductor
The IHLP-2525EZ-01 is a high-current, shielded power inductor designed for use in notebook, desktop, and server applications. It offers low DCR, high saturation current, and stable inductance over temperature. Ideal for high-efficiency POL converters, DC/DC circuits, and FPGA power supplies, this inductor features a powdered iron core for soft saturation and minimal buzz noise. Its compact 2525 package supports high transient currents, ensuring reliable performance in demanding applications, with an operating temperature range from -55°C to +125°C and rated voltages up to 75 V.
Vishay IHLP2525EZER2R2M01 Power Inductor Specifications:
- Inductance: 0.56 µH, 0.68 µH, 0.82 µH, 1.0 µH, 1.5 µH, 2.2 µH, 3.3 µH, 5.6 µH, 8.2 µH
- Inductance Tolerance: ±20%
- Current Rating: up to 20 A, depending on inductance
- Saturation Current: varies with inductance (e.g., 12 A for 0.56 µH)
- Operating Temperature Range: -55°C to +125°C
- Maximum Voltage: 75 V
- DCR (typical): as low as 34 mΩ (for 0.56 µH)
- Dimensions: 0.285 x 0.285 inches (7.24 x 7.24 mm)
- Material: Powdered iron core, shielded construction
- RoHS Compliant: Yes
- Application: Power supplies, POL converters, FPGA, DC/DC converters
- Packaging: Tape and reel, lead-free
Buy the Vishay Series IHLP High Saturation Power Inductor: IHLP2525EZ-01
Purchase the Vishay IHLP2525EZ-01 power inductor online today to enhance your electronic projects. This high-current, shielded inductor provides low DCR, stable inductance, and excellent saturation capabilities ideal for power supplies, POL converters, and FPGA applications. Its compact size and wide operating temperature range guarantee reliable performance. Take advantage of fast delivery and competitive pricing by ordering now and ensure your designs operate efficiently and dependably in demanding environments.
Order your Vishay Series IHLP2525EZ-01 high saturation power inductor today and ensure reliable power delivery in your high-current applications.
Frequently Asked Questions
Where can I buy Vishay IHLP2525EZER2R2M01?
You can click on the BUY or RFQ button to purchase IHLP2525EZER2R2M01 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part IHLP2525EZER2R2M01?
You can download the IHLP2525EZER2R2M01 datasheet or visit the Vishay website for support.
Who is the manufacturer of IHLP2525EZER2R2M01?
Vishay
