Vishay MAL210118682E3 Power Aluminum Capacitor
These high-quality aluminum electrolytic capacitors are designed for power applications requiring high ripple current handling, long lifespan, and reliable performance. They are polarized, feature screw terminals, and have pressure relief mechanisms for safety. Suitable for buffering, filtering, motor drives, inverters, UPS, and pulsed power supplies, these capacitors are available in multiple case sizes up to 90 mm x 220 mm, with long useful life of 10,000 to 15,000 hours at +85°C, and are RoHS compliant for environmental safety.
Vishay MAL210118682E3 Power Aluminum Capacitor Specifications:
- Case Sizes: up to 90 mm x 220 mm
- Useful Life: 10,000 to 15,000 hours at +85°C
- Capacitance Range: 220 μF to 1 F (E6 series), 3300 μF to 470,000 μF (102 series)
- Rated Voltage: 25 V to 450 V
- Temperature Range: -40°C to +85°C
- Pressure Relief System: In sealing
- RoHS compliant
- Leakage Current: < 0.002 Cp x Up after 5 min at Ur
- ESR: Low ESR at 100 Hz, varies with size
- Dimensions: D x L varies with model, standard sizes include 35x60, 50x80, 76x146 mm
- Materials: Aluminum case with blue sleeve insulation, non-solid electrolyte
- Markings: Capacitance, voltage, series, date code, manufacturer ID
- Standards: IEC 60384-4, EN 130300
- Endurance: 2000-5000 hours at 85°C depending on size
- Applications: Buffering, filtering, motor drives, inverters, UPS, pulsed power supplies
Buy the Buy Vishay BCcomponents Power High Ripple Current Aluminum Capacitors Part Number MAL210118682E3 Online
Enhance your power systems with Vishay BCcomponents power aluminum electrolytic capacitors. Designed for high ripple current, long lifespan, and safety features like pressure relief, these capacitors ensure stable performance in buffering, filtering, motor drives, inverters, UPS, and pulsed power supplies. Available in various sizes up to 90 mm x 220 mm, with long operational life of 10,000 to 15,000 hours at +85°C, these RoHS-compliant components meet rigorous standards and are ideal for industrial, automation, and power management applications. Purchase online today for reliable power solutions.
Buy Vishay BCcomponents MAL210118682E3 now and experience unmatched reliability and performance in power electronics and filtering applications.
