Vishay MAL210127153E3 High Ripple Aluminum Capacitor
High ripple current aluminum electrolytic capacitor designed for buffering, filtering, motor drives, inverters, UPS, and pulsed power supplies. Features long lifespan up to 15,000 hours at +85°C, RoHS compliance, pressure relief in sealing, low ESR, large cylindrical aluminum case with blue insulation sleeve, and available in various case sizes up to 90 mm x 220 mm. Suitable for high ripple current applications with durable screw terminals and high-temperature endurance. The capacitors provide reliable performance in demanding industrial and power electronics environments, ensuring stability and longevity.
Vishay MAL210127153E3 High Ripple Aluminum Capacitor Specifications:
- Capacitance range: 220 μF to 1 F
- Voltage range: 25 V to 450 V
- Temperature range: -40°C to +85°C
- Dimensions: up to 90 mm x 220 mm case sizes
- Useful life at 85°C: up to 15,000 hours
- Endurance test at 85°C: 2000 hours
- Pressure Relief: yes
- Low ESR for high ripple applications
- RoHS compliant
- Case Material: Cylindrical aluminum with blue sleeve insulation
- Markings: rated capacitance, tolerance, voltage, date code
- Maximum ripple current multiplier: 1.6 at 70°C, 1.3 at 400 Hz, 1.25 with air flow
- Impedance at 20 kHz: specified per model
- Mechanical connection: screw terminals, torque up to 2.5 Nm
- Available in bulk packaging, case sizes up to 76 mm x 220 mm
Buy the Vishay Series High Ripple Aluminum Capacitor: MAL210127153E3
Enhance your power electronics with Vishay BCcomponents high ripple current aluminum capacitors. Designed for long life up to 15,000 hours at +85°C, they excel in buffering, filtering, motor drives, and UPS systems. Featuring RoHS compliance, pressure relief, low ESR, and large case sizes up to 90 mm x 220 mm, these capacitors deliver reliable performance under demanding conditions. Easy to install with screw terminals, they optimize durability, stability, and efficiency in industrial and power supply applications. Purchase online today for proven quality.
Get Vishay BCcomponents PHR-ST high ripple current aluminum capacitor today—built for precision and long-lasting durability in demanding power applications.
Frequently Asked Questions
Where can I buy Vishay MAL210127153E3?
You can click on the BUY or RFQ button to purchase MAL210127153E3 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part MAL210127153E3?
You can download the MAL210127153E3 datasheet or visit the Vishay website for support.
Who is the manufacturer of MAL210127153E3?
Vishay
