Vishay MAL216050101E3 Aluminum Electrolytic Capacitors
These are high-temperature, low impedance aluminum electrolytic capacitors suitable for industrial, automotive, telecommunications, and military power supply applications. They feature a useful life of up to 2000 hours at 150 °C, very low ESR, and excellent ripple current capability. Polarized with non-solid electrolyte, they have radial leads, cylindrical aluminum case with pressure relief, and an insulated blue PET sleeve. They are RoHS compliant, highly reliable, and qualified under AEC-Q200 standards for demanding environments, making them ideal for smoothing, filtering, and buffering in harsh conditions.
Vishay MAL216050101E3 Aluminum Electrolytic Capacitors Specifications:
- Capacitance range: 33 UF to 3300 UF
- Tolerance on rated capacitance: +20%
- Rated voltage: 16 V to 50 V
- Nominal case sizes: 10 x 12 mm to 18 x 35 mm
- Temperature range: -55°C to +150°C
- Useful life at 150 °C: 1000 to 2000 hours
- Shelf life at 0 V, 150°C: 1000 hours
- Endurance test duration at 150°C: 1000 to 1500 hours
- Ripple current capability: Rated at 100 kHz and 150°C
- Compliance: RoHS, AEC-Q200 qualified
- Case material: Cylindrical aluminum with pressure relief
- Leads: Radial, insulated with blue PET sleeve
Buy the Buy Vishay BCcomponents Aluminum Electrolytic Capacitors Part Number MAL216050101E3 Online
Enhance your power supply designs with Vishay BCcomponents aluminum electrolytic capacitors. These reliable components offer high temperature operation up to 150°C, low ESR, and long useful life. Suitable for smoothing, filtering, and buffering in industrial, automotive, and telecommunications applications, they feature radial leads, cylindrical aluminum cases with pressure relief, and RoHS compliance. Easy to order online, ensuring swift delivery and trusted quality for all demanding electronic projects. Optimize your systems today with top-tier electrolytic capacitors.
Buy Vishay BCcomponents aluminum electrolytic capacitors with high temperature tolerance and low impedance now and experience unmatched reliability and performance.
Frequently Asked Questions
Where can I buy Vishay MAL216050101E3?
You can click on the BUY or RFQ button to purchase MAL216050101E3 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part MAL216050101E3?
You can download the MAL216050101E3 datasheet or visit the Vishay website for support.
Who is the manufacturer of MAL216050101E3?
Vishay
