Vishay MAL216051339E3 Aluminum Electrolytic Capacitors
These aluminum electrolytic capacitors feature radial mounting, enhanced high-temperature stability up to 150°C, and low impedance. They offer useful life up to 2000 hours at 150°C and are suitable for power supplies, smoothing, filtering, and buffering in industrial, automotive, telecommunications, and military applications. Constructed with a cylindrical aluminum case, they include pressure relief and blue PET insulation. They are AEC-Q200 qualified, polarization design with non-solid electrolyte, charge/discharge proof, and RoHS compliant, ensuring high reliability and stable performance over extended periods.
Vishay MAL216051339E3 Aluminum Electrolytic Capacitors Specifications:
- Capacitance range: 33 UF to 3300 UF
- Rated voltage: 16 V to 50 V
- Temperature range: -55°C to +150°C
- Endurance: 1000 h to 2000 h at 150°C
- Useful life at 150°C: up to 2000 hours
- Physical sizes: 10 x 12 mm to 18 x 35 mm
- Dimensions vary with case size, typical diameter 10-18 mm, length 12-35 mm
- Construction: Cylindrical aluminum case with pressure relief, blue PET sleeve insulation
- Ripple current capability: up to 600 mA at 100 kHz and 150°C
- Compliance: RoHS, AEC-Q200 qualified
- Leakage current: < specified limits after 2 min at rated voltage
- Dissipation factor: low, specified at 100 Hz
- Impedance: minimal at 100 kHz, specified in datasheet
- Certifications: RoHS, AEC-Q200
- Markings: includes capacitance, voltage, factory code, series number
Buy the Vishay Series RLA Aluminum Electrolytic Capacitors: MAL216051339E3
Order Vishay 160 RLA aluminum electrolytic capacitors online today for your power supply and filtering needs. These high-temperature, low impedance capacitors ensure excellent stability, long useful life up to 2000 hours at 150°C, and meet strict RoHS and AEC-Q200 standards. Perfect for automotive, industrial, telecommunications, and military applications, they provide reliable performance for smoothing, filtering, and buffering. Secure your supply chain by purchasing online and benefit from fast delivery, quality assurance, and technical support for all your high-reliability applications.
Buy Vishay 160 RLA capacitors now and experience unmatched reliability and performance in power supplies, filtering, and buffering for industrial, automotive, and telecom applications.
