Vishay MAL222051024E3 Energy Storage Capacitor
The ENYCAP energy storage capacitor series offers high-capacity, polarized electric double layer capacitors with 100F capacitance and 2.7V rated voltage, designed for efficient energy storage and rapid charge/discharge cycles. These compact 20x40mm devices have excellent cycle life exceeding 500,000 cycles, wide temperature tolerance from -40°C to +85°C, and are RoHS compliant, making them suitable for various energy storage applications requiring high energy density, durability, and reliable performance in space-constrained environments.
Vishay MAL222051024E3 Energy Storage Capacitor Specifications:
- Capacitance: 100 F
- Rated Voltage: 2.7 V
- Maximum Voltage (Tmax 85°C): 2.3 V
- Dimensions: Diameter 20.5 mm, Length 43.5 mm, Thickness 1.0 mm, Width F 7.5 ± 0.5 mm
- Weight: 20.0 g
- Temperature Range: -40°C to +85°C
- Cycle Life: > 500,000 cycles
- Leakage Current after 72 hours: 500 µA
- Maximum ESR at 20°C: 15 mΩ
- Maximum Surge Voltage: 2.85 V
- Soldering: Wave or hand soldering permitted, follow guidelines
- Compliance: RoHS
- Operating Energy Storage: 0.07 Wh at 2.7V, 85°C
- Specific Energy: 3.7 Wh/kg at 2.7V
- Useful Life: 1000 hours at Ur and Tmax
Buy the VISHAY Series ENYCAP Energy Storage Capacitor: MAL222051024E3
Enhance your electronic projects with the VISHAY MAL222051024E3 energy storage capacitor. Featuring 100F capacitance, 2.7V rating, and durable design, it provides reliable energy storage with rapid charge/discharge cycles. Its compact size of 20x40mm ensures ease of integration into space-constrained devices. Designed for over half a million cycles and wide temperature operation from -40°C to +85°C, this RoHS-compliant capacitor guarantees longevity and consistent performance in demanding applications. Buy online now for premium energy solutions.
Get VISHAY MAL222051024E3 energy storage capacitor today—built for high energy density and long-lasting durability.
Frequently Asked Questions
Where can I buy Vishay MAL222051024E3?
You can click on the BUY or RFQ button to purchase MAL222051024E3 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part MAL222051024E3?
You can download the MAL222051024E3 datasheet or visit the Vishay website for support.
Who is the manufacturer of MAL222051024E3?
Vishay
