Vishay MAL224658102E3 Electrolytic Capacitor
This high-temperature aluminum electrolytic capacitor offers a long operational life of up to 6000 hours at 125°C, with very low ESR and high ripple current capacity, making it suitable for industrial, automotive, and telecommunications power supply applications. Features include excellent vibrational resistance up to 50 g, polarizing design with non-solid electrolyte, and cylindrical aluminum case with blue PET insulation. Rated for various nominal sizes and voltages, it ensures high stability, reliability, and compliance with AEC-Q200 standards, ideal for filtering, smoothing, and buffering duties.
Vishay MAL224658102E3 Electrolytic Capacitor Specifications:
- Nominal case sizes: 16 x 20 to 18 x 35 mm
- Rated capacitance: 390 uF to 6800 uF with 20% tolerance
- Rated voltage: 16V to 63V
- Temperature range: -55°C to +125°C
- Endurance: 3000–6000 hours at 125°C
- Useful life: 4000–6000 hours at 125°C, 1.8x In at 40°C
- Dimensions: varies by size, e.g., 16 x 20 mm, 18 x 35 mm
- Vibration resistance: up to 50 g, no damage or electrolyte leakage
- RoHS compliant, AEC-Q200 qualified
- Construction: Cylindrical aluminum case, blue PET sleeve insulation
- Ripple current: high, suitable for filtering and smoothing
- Leakage current: low after 2 minutes at Up
Buy the Vishay Series RTI-V Aluminum Electrolytic Capacitors: MAL224658102E3
Discover the Vishay MAL224658102E3 aluminum electrolytic capacitor, engineered for long life and exceptional stability at high temperatures. Perfect for industrial, automotive, and telecommunications power supplies, these radial capacitors feature low ESR, high ripple current, and vibration resistance up to 50 g. Their robust construction with cylindrical aluminum case and blue PET insulation ensures durability and reliable performance. Purchase online now to enhance your power management solutions with a trusted, high-quality component designed for demanding environments.
Get Vishay MAL224658102E3 today—built for precision, high temperature, and reliable power filtering.
