Vishay MBB02070C1002FCT00 Thin Film Resistor
Professional thin film leaded resistors suitable for all fields requiring reliability and stability. Manufactured with homogeneous metal alloy film on ceramic, these resistors feature a light blue protective coating for electrical and mechanical protection. They are available with various termination options, comply with RoHS, Halogen-Free standards, and are approved within IECQ-CECC quality system. Applications include industrial, automotive, telecommunication, and medical equipment demanding precise, long-lasting performance with resistance ranges up to 22 MΩ and TCR as low as +25 ppm/K.
Vishay MBB02070C1002FCT00 Thin Film Resistor Specifications:
- Resistance Range: 0.22 Q to 22 MQ
- Resistance Tolerance: +5 %, ±1 %, ±2 %
- Temperature Coefficient: +50 ppm/K; +25 ppm/K for selected versions
- Rated Dissipation: 0.4W (MBA/SMA 0204), 0.6W (MBB/SMA 0207), 1.0W (MBE/SMA 0414)
- Operating Voltage: 200 V (MBA/SMA 0204), 350 V (MBB/SMA 0207), 500 V (MBE/SMA 0414)
- Operating Temperature Range: -55°C to 155°C
- Peak Film Temperature: 155°C
- Insulation Voltage: 300 V to 800 V depending on type
- Resistance Drift: <0.25% after 1000 hours at rated power, up to <15% over 225,000 hours
- Standards Compliance: RoHS, Halogen-Free, IECQ-CECC, EN 140101-806
Buy the Buy Vishay Beyschlag Professional Thin Film Leaded Resistors Part Number MBB02070C1002FCT00 Online
Order the Vishay Beyschlag Thin Film Resistor Part Number MBB02070C1002FCT00 online today. This high-reliability resistor offers excellent stability, low TCR, and resistance up to 22 megaohms, suitable for industrial, automotive, and medical electronics. Manufactured with strict quality control, it features RoHS and Halogen-Free compliance. Its robust construction ensures minimal drift over time, and it supports high operating voltages with rated dissipation up to 1W. Perfect for demanding projects requiring durability, precision, and environmental resilience—order now to ensure optimal performance in your critical applications.
Get Vishay Beyschlag MBB02070C1002FCT00 today—designed for precision and long-lasting durability in demanding electronic applications.
Frequently Asked Questions
Where can I buy Vishay MBB02070C1002FCT00?
You can click on the BUY or RFQ button to purchase MBB02070C1002FCT00 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part MBB02070C1002FCT00?
You can download the MBB02070C1002FCT00 datasheet or visit the Vishay website for support.
Who is the manufacturer of MBB02070C1002FCT00?
Vishay
