Vishay MKP1847510354K2 AC Filtering Capacitor
The MKP1847 series AC filtering radial film capacitor features polypropylene dielectric and metallized film electrodes. It is equipped with tinned wire terminals and is sealed in a flame-retardant plastic case with resin. Suitable for AC filtering, UPS systems, renewable energy grid interfaces, harmonic filtering, and welding equipment. The capacitor offers high peak current capabilities, long service life, and is available with ±5% or 10% capacitance tolerance. It is also a green environmentally friendly product.
Vishay MKP1847510354K2 AC Filtering Capacitor Specifications:
- Dielectric: Polypropylene film
- Construction: Mono and internal serial
- Terminals: Tinned wire
- Sealing: Flame retardant plastic case with resin
- Capacitance range: 1 UF to 70 UF
- Capacitance tolerance: +5% and 10%
- Maximum continuous AC voltage: 230 Vac to 440 Vac
- Maximum application temperature: 105 °C
- Climatic testing class: 40/85/56
- Self inductance: <1 nH per mm of lead spacing
- Life expectancy: >60,000 hours at Unac
- Insulation resistance: >10,000 s at 500 V
- Peak current capabilities: High peak current features
- RoHS compliant and environmentally friendly
Buy the Buy Vishay MKP1847 AC Filtering Part Number MKP1847510354K2 Online
Purchase your Vishay MKP1847 series AC filtering film capacitor online today to benefit from high-quality polypropylene dielectric technology, long service life, and environmentally friendly design. This capacitor is ideal for AC line filtering, UPS systems, renewable energy grid connection, harmonic filtering, and welding equipment. With a capacitance range from 1 UF to 70 UF and available with ±5% or 10% tolerances, it provides dependable performance and robust construction, ensuring your projects run smoothly and efficiently.
Order your Vishay MKP1847510354K2 series AC filtering capacitor today and ensure reliable performance for your industrial applications.
Frequently Asked Questions
Where can I buy Vishay MKP1847510354K2?
You can click on the BUY or RFQ button to purchase MKP1847510354K2 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part MKP1847510354K2?
You can download the MKP1847510354K2 datasheet or visit the Vishay website for support.
Who is the manufacturer of MKP1847510354K2?
Vishay
