Vishay P13LFL106MAB10 Sealed Cermet Potentiometer
The P13LFL106MAB10 is a fully sealed cermet potentiometer suitable for military and professional applications. It features a 270° + 10° electrical travel, high power rating of 1.5 W at 70°C, and tight temperature coefficient of 75 ppm/°C. Made with a cermet element and a sealed case, it offers excellent stability and mechanical strength, ideal for demanding environments. The device includes optional shaft locking and sealing features, with diverse mounting options, sizes, and tapers, complying with RoHS standards and tested for durability and reliability in extreme conditions.
Vishay P13LFL106MAB10 Sealed Cermet Potentiometer Specifications:
- Electrical travel: 270° + 10°
- Power rating: 1.5 W at 70°C
- Resistance range: 1kΩ to 2.2MΩ
- Taper types: linear and logarithmic
- Temperature coefficient: typical 75 ppm/°C
- Insulation resistance: > 10 MΩ at 300 VDC
- Dielectric strength: 2000 V RMS
- Mechanical travel: 300° + 5°
- Operating torque: typical 2.85 oz.in
- Sealing: Fully sealed IP67
- Ambient temperature: -55°C to +125°C
- Terminals: 3, Sn plated
- Weight: 6g to 18g
- Climatic category: 55/125/56
- End resistance: typical 10Ω
- Limiting element voltage: 350 V
Buy the Buy Vishay P13LFL106MAB10 Fully Sealed Cermet Potentiometer Online
Purchase the Vishay P13LFL106MAB10 sealed cermet potentiometer online today. Designed for military and professional use, it provides excellent stability with a sealed IP67 case, a 270° travel, and a 1.5 W power rating at 70°C. Its robust construction ensures durability in extreme conditions, making it ideal for demanding industrial, military, and instrumentation applications. Benefit from fast online ordering, reliable performance, and consistent quality tailored for your rugged projects and precise control needs.
Order your Vishay P13LFL106MAB10 sealed cermet potentiometer today and enhance your rugged equipment with reliable stability and high-temperature performance.
Frequently Asked Questions
Where can I buy Vishay P13LFL106MAB10?
You can click on the BUY or RFQ button to purchase P13LFL106MAB10 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part P13LFL106MAB10?
You can download the P13LFL106MAB10 datasheet or visit the Vishay website for support.
Who is the manufacturer of P13LFL106MAB10?
Vishay
