Vishay PLTT0805Z2002AGTS High-Temperature Precision Resistor
Vishay Dale Thin Film precision low TCR high temperature surface-mount chip resistor offers exceptional stability, ultra low noise, and high temperature resistance from -55°C to 215°C. Featuring +5 ppm/°C TCR, 0.02% tolerance, and gold terminations, these resistors are suitable for oil industry applications requiring long-term stability under high temperatures. They provide low voltage coefficient, corrosion resistance, and stable performance with stability at 0.5% after 2000 hours at 215°C. Available in various case sizes with wide resistance ranges, these resistors meet RoHS and UL 94 V-0 flame resistance standards.
Vishay PLTT0805Z2002AGTS High-Temperature Precision Resistor Specifications:
- Resistance Range: 250Ω to 3MΩ
- TCR: +5 ppm/°C
- Tolerance: ±0.02%
- Operating Temperature Range: -55°C to +215°C
- Stability: 0.5% at 2000 hours at 215°C, 25% rated power
- Noise: Less than -35 dB (typical)
- Voltage Coefficient: 0.1 ppm/V (typical)
- Case Sizes: 0805, 1206, 2010, 2512
- Power Ratings: 250mW, 400mW, 800mW, 1000mW respectively
- Material: Passivated Nichrome resistive film with gold terminations
- Flame Resistance: UL 94 V-0
- RoHS Compliant: Yes (excluding lead terminations)
- Environmental Reliability: Resistance to thermal shock, moisture, solder heat, and high temperature exposure
- Dimensions (Approximate): 0805: 0.080 x 0.050 inches, 1206: 0.126 x 0.063 inches, 2010: 0.209 x 0.098 inches, 2512: 0.259 x 0.124 inches
Buy the Vishay PLTT0805Z2002AG – Reliable High-Temperature Thin Film Resistor for Industrial Applications
Purchase Vishay PLTT0805Z2002AG today—designed for industrial applications requiring exceptional temperature stability, low noise, and high reliability. These surface-mount resistors feature +5 ppm/°C TCR, 0.02% tolerance, and gold terminations, ensuring optimal performance under harsh conditions. Ideal for oil industry equipment, they offer long-term stability with minimal drift even after 2000 hours at 215°C. With various case sizes and resistance options, this resistor guarantees durability, compliance with RoHS, and flame resistance, making it your perfect component for demanding environments.
Get Vishay PLTT0805Z2002AG today—built for precision, stability, and long-lasting durability in high-temperature environments.
Frequently Asked Questions
Where can I buy Vishay PLTT0805Z2002AGTS?
You can click on the BUY or RFQ button to purchase PLTT0805Z2002AGTS from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part PLTT0805Z2002AGTS?
You can download the PLTT0805Z2002AGTS datasheet or visit the Vishay website for support.
Who is the manufacturer of PLTT0805Z2002AGTS?
Vishay
