Vishay RCWE0603R160FKEA Low Resistance Chip Resistor
The RCWE series is a range of thick film surface mount chip resistors designed for high-precision, low-resistance applications. These wraparound resistors feature extremely low resistance values from 0.01 Q to 0.976 Q, making them ideal for current sensing and shunt measurement in various industrial and electronic circuits. Manufactured with a metal glaze on high-quality ceramic, they include RoHS-compliant, lead-free contacts on a Ni barrier layer. Suitable for a wide operating temperature range up to 155°C, they offer stability, durability, and high insulation resistance, complying with international standards.
Vishay RCWE0603R160FKEA Low Resistance Chip Resistor Specifications:
- Resistance Range: 0.01 Q to 0.976 Q
- Temperature Range: -55°C to +155°C
- Maximum Operating Voltage: >75 V to >300 V depending on model
- Insulation Resistance: >10^9 Ω
- RoHS Compliant, Lead-free, Halogen-free
- Material: Metal glaze on ceramic substrate
- Package Types: Tape and reel, including 8 mm punched paper and embossed plastic
- Dimensions: RCWE0402 - 1.03 x 0.54 mm, RCWE0603 - 1.64 x 0.84 mm, RCWE0805 - 2.04 x 1.34 mm, RCWE1206 - 3.1 x 1.6 mm, RCWE1210 - 3.14 x 2.5 mm, RCWE2010 - 5.0 x 2.54 mm, RCWE2512 - 6.34 x 3.15 mm
- Power Rating: Depends on temperature and substrate, up to 0.2 W for smaller sizes and higher for larger
- Resistance Tolerance: ±1%, ±2%, up to ±5%
- Temperature Coefficient: +100 ppm/°C to +700 ppm/°C depending on model
- Compliance: RoHS, Halogen-free according to IEC 61249-2-21
- Packaging: Reels, with specific tape widths and piece counts per reel
Buy the Vishay RCWE0603 – Reliable Low-Value Resistors for Industrial Applications
Purchase the Vishay RCWE series low resistance surface mount resistors online today. Perfect for current sensing and shunt applications, these resistors combine precision, reliability, and RoHS compliance. With resistance values from 0.01 Q to 0.976 Q, they are suitable for industrial electronics, measuring devices, and high-accuracy circuits. Available in various sizes with tape and reel packaging, they ensure ease of handling and installation. Get your supply now and improve your circuit performance with high-quality, durable resistors with excellent thermal stability and insulation resistance.
Order your Vishay Series RCWE0603 low resistance chip resistor today and enhance your electronic and industrial projects with dependable, high-precision components.
Frequently Asked Questions
Where can I buy Vishay RCWE0603R160FKEA?
You can click on the BUY or RFQ button to purchase RCWE0603R160FKEA from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part RCWE0603R160FKEA?
You can download the RCWE0603R160FKEA datasheet or visit the Vishay website for support.
Who is the manufacturer of RCWE0603R160FKEA?
Vishay
