Vishay SFH6345X017T High-Speed Optocoupler
The SFH6345-X017T from Vishay is a high-noise immunity, high-speed optocoupler in an 8-pin surface-mount DIP package. It features a GaAlAs infrared LED optically coupled to an integrated detector that includes a photodiode and a high-speed transistor. This device includes a Faraday shield on the detector to enhance dV/dt immunity. Capable of transmitting signals up to 2 MHz, it is ideal for industrial communication bus isolation and isolated drive circuits such as IGBT and intelligent power modules (IPMs). Key specifications include a maximum forward voltage of 1.9 V at 16 mA, reverse current of 10 µA, and a coupling capacitance of 0.6 pF. It offers a high data transmission rate of 1 Mbps, a high isolation test voltage of 5300 VRMS, and is UL listed under file no. E52744. Its features include low saturation voltage, TTL-compatible open-collector output, high common mode transient immunity (≥ 15 kV/µs), and operation over an ambient temperature range of -55°C to +100°C. Applications encompass signal processing, communications, and networking.
Vishay SFH6345X017T High-Speed Optocoupler Specifications:
- Maximum forward voltage: 1.9 V at 16 mA
- Reverse current: 10 µA
- Coupling capacitance: 0.6 pF
- Isolation test voltage: 5300 VRMS
- Operating temperature range: -55°C to +100°C
- Ambient temperature: -55°C to +100°C
- Output voltage: 0.5 to 25 V
- Output current: 8 mA
- Power dissipation: 100 mW
- Data transmission rate: 1 Mbps
- High common mode transient immunity: ≥ 15 kV/µs
- Package: 8-pin surface-mount DIP
- Material categorization: for definitions of compliance see Vishay documentation
- UL-listed: file no. E52744
- Faraday shield for enhanced dV/dt immunity
- Designed for industrial communication and isolated driver circuits
Buy the Vishay Series SFH Series High Noise Immunity Optocoupler: SFH6345X017T
Purchase the Vishay SFH6345X017T online today, delivering superior noise immunity and high-speed data transmission for industrial communication and control applications. With a wide temperature range, UL certification, and excellent dV/dt immunity, this optocoupler guarantees dependable isolation and signal integrity. Perfect for gate drivers, signal processing, and networking equipment, it ensures reliable operation even in challenging environments. Get your high-performance, UL-listed SFH6345X017T and enhance your automation and industrial control projects with trusted Vishay quality, available now for quick online ordering.
Order your Vishay Series SFH6345X017T high-noise immunity optocoupler today and ensure reliable signal isolation for industrial control and communication systems.
