Vishay SS36E357T Schottky Diode
The SS36E357T is a high-efficiency surface-mount Schottky barrier rectifier designed for low-voltage, high-frequency applications such as inverters, DC/DC converters, and polarity protection circuits. It features a low forward voltage drop, high surge capability, and guardring for overvoltage protection. The package is DO-214AB (SMC), suitable for automated placement, with RoHS compliance and AEC-Q101 qualification. Its maximum repetitive peak reverse voltage ranges from 20 V to 60 V, with up to 3.0 A forward current and 100 A surge current, making it ideal for demanding power diode applications.
Vishay SS36E357T Schottky Diode Specifications:
- Maximum repetitive peak reverse voltage: 20 V to 60 V
- Maximum RMS voltage: 14 V to 42 V
- Maximum DC blocking voltage: 20 V to 60 V
- Maximum average forward rectified current: 3.0 A
- Surge current: 100 A
- Maximum junction temperature: -55°C to +150°C
- Thermal resistance: 55 °C/W
- Package: DO-214AB (SMC)
- Material: Matte tin plated leads
- Compliance: RoHS, AEC-Q101 qualified
- Dimensions: 0.126 to 0.280 inches (3.20 to 7.11 mm) length
- Polarity: Cathode band
- Alarm overvoltage protection guardring
- Material meets UL 94 V-0 flammability rating
- Operating and storage temperature range: -55°C to +150°C
Buy the Buy Vishay Schottky Barrier Rectifier Part Number SS36E357T Online
Enhance your power management systems with the Vishay SS36E357T Schottky barrier rectifier, offering low forward voltage drop, high surge capacity, and compact surface-mount design. Perfect for high-frequency inverters, DC/DC converters, and polarity protection. Its robust package and RoHS compliance ensure easy integration and environmentally friendly manufacturing. With a maximum voltage range of 20 V to 60 V and a surge current of 100 A, this diode guarantees high efficiency and reliability, making it essential for demanding electronic power applications. Purchase online today for fast delivery and dependable performance.
Order your Vishay Series SS36E357T high-efficiency surface-mount rectifier today and ensure reliable, low-loss power conversion in your electronic projects.
Frequently Asked Questions
Where can I buy Vishay SS36E357T?
You can click on the BUY or RFQ button to purchase SS36E357T from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part SS36E357T?
You can download the SS36E357T datasheet or visit the Vishay website for support.
Who is the manufacturer of SS36E357T?
Vishay
