Vishay TS63Y102KT20 Multi-Turn Surface Mount Cermet Trimmer
The TS63Y102KT20 is a fully sealed, multi-turn surface mount cermet trimmer designed for precise resistance adjustment in PCB applications. It features a 14 turns + 2 resistance travel range from 10Ω to 2MΩ, with a power rating of 0.25 W at 70°C and a temperature range of -55°C to +155°C. The device offers low contact resistance variation down to 2% Rn, high dielectric strength of 1000V, and is RoHS compliant. Suitable for calibration and tuning in industrial electronics, it ensures stable performance even under harsh environments.
Vishay TS63Y102KT20 Multi-Turn Surface Mount Cermet Trimmer Specifications:
- Resistance Range: 10Ω to 2MΩ
- Power Rating: 0.25 W at 70°C
- Resistance Tolerance: ±10% (standard), ±25% (on request)
- Electrical Travel: 14 turns + 2
- Mechanical Travel: 15 turns + 5
- Temperature Range: -55°C to +155°C
- Dielectric Strength: 1000V RMS
- Insulation Resistance: 10^6 MΩ
- Sealed container, RoHS compliant
- Climatic Category: 56/125/56
- Vibration and Shock resistant
- End Resistance: Typical 12Ω
- End Contact Resistance: Typical 1Ω
- Limit Voltage: 250V
- Wiper Travel: Approximately 50%
- Environmental: Fully sealed, RoHS compliant.
Buy the VISHAY TS63Y102KT20 – Reliable Multi-Turn Surface Mount for Industrial Applications
Order the VISHAY TS63Y102KT20 online today to ensure precise resistance adjustments in your industrial electronics projects. This fully sealed, RoHS compliant trimmer offers high stability, low resistance variation, and excellent environmental resilience. Designed for PCB applications, it features a resistance range up to 2MΩ, making it ideal for calibration, tuning, and fine adjustment in demanding settings. Easy to install on surface-mount assemblies, it guarantees durable, accurate performance even under high temperatures and vibration conditions.
Buy VISHAY TS63Y102KT20 now and experience unmatched reliability and performance in precision electronic adjustments.
Frequently Asked Questions
Where can I buy Vishay TS63Y102KT20?
You can click on the BUY or RFQ button to purchase TS63Y102KT20 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part TS63Y102KT20?
You can download the TS63Y102KT20 datasheet or visit the Vishay website for support.
Who is the manufacturer of TS63Y102KT20?
Vishay
