WAGO 231305037000 5-pole Female Plug Connector
The WAGO 231-305/037-000 is a versatile 5-pole female plug connector within the MCS system. Its CAGE CLAMP technology simplifies wiring, allowing for both vertical and horizontal actuation. The connector is designed for universal conductor compatibility, accommodating solid, stranded, and ferruled conductors. Integrated test ports facilitate easy circuit testing. It is suitable for applications requiring reliable and efficient power distribution in industrial machinery, control panels, and automation systems. The connector's robust design and material composition ensure durability and long-term performance.
WAGO 231305037000 5-pole Female Plug Connector Specifications:
- Rated voltage (III / 3): 320 V
- Rated impulse voltage (III / 3): 4 kV
- Rated voltage (III / 2): 320 V
- Rated impulse voltage (III / 2): 4 kV
- Rated voltage (II / 2): 630 V
- Rated impulse voltage (II / 2): 4 kV
- Rated current: 16 A
- Rated voltage UL (Use Group B): 300 V
- Rated current UL (Use Group B): 15 A
- Rated voltage UL (Use Group D): 300 V
- Rated current UL (Use Group D): 10 A
- Rated voltage per UL 1977 (factory wiring only): 600 V
- Rated current per UL 1977 (factory wiring only): 15 A
- Rated voltage CSA (Use Group B): 300 V
- Rated current CSA (Use Group B): 15 A
- Rated voltage CSA (Use Group D): 300 V
- Rated current CSA (Use Group D): 10 A
- Connection technology: CAGE CLAMP®
- Actuation type: Operating tool
- Solid conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
- Fine-stranded conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
- Fine-stranded conductor with ferrule with plastic collar: 0.25 … 1.5 mm²
- Fine-stranded conductor with ferrule without plastic collar: 0.25 … 2.5 mm²
- Strip length: 8 … 9 mm / 0.31 … 0.35 inch
- No. of poles: 5
- Total number of connection points: 5
- Total number of potentials: 5
- Number of connection types: 1
- Number of levels: 1
- Conductor entry direction to mating direction: 0 °
- Pin spacing: 5.08 mm / 0.2 inch
- Width: 42 mm / 1.654 inch
- Height: 14.3 mm / 0.563 inch
- Depth: 29.6 mm / 1.165 inch
- Contact type (pluggable connector): Female connector/socket
- Mismating protection: No
- Locking of plug-in connection: locking lever
- Color: orange
- Insulating material: Polyamide 66 (PA 66)
- Flammability class per UL94: V0
- Clamping spring material: Chrome nickel spring steel (CrNi)
- Contact material: Copper alloy
- Contact plating: tin-plated
- Fire load: 0.176 MJ
- Weight: 10.6 g
- Limit temperature range: -60 … +85 °C
