WAGO 280519 Double Deck Terminal Block
The WAGO 280-519 double-deck terminal block provides a robust and space-saving solution for connecting multiple conductors on a DIN rail. Its cage clamp connection ensures reliable termination, minimizing the risk of disconnection. Designed for front-entry wiring, this terminal block is ideal for applications requiring high current carrying capacity and voltage isolation in industrial control panels, power distribution systems, and automation equipment. The double-deck design allows for increased circuit density, optimizing space utilization within enclosures.
WAGO 280519 Double Deck Terminal Block Specifications:
- Cross section from [mm²]: 0,08 mm²
- Cross section to [mm²]: 2,5 mm²
- Cross section from [AWG]: 28 AWG
- Cross section to [AWG]: 14 AWG
- Connection method: CAGE CLAMP®CONNECTION
- Voltage UL: 300 V
- Voltage CSA: 300/600 V
- Current UL: 15 A
- Current CSA: 20/5 A
- Measured voltage EN: 500 V
- Measured shock voltage: 6 kV
- Pollution degree: 3
- Current intensity EN: 20 A
- Weight: 10,057 g
- Color: grey
- Wiring type: Front-entry
- No. of connection Points: 4
- No. of potentials: 2
- Height: 58,5 mm
- Height (in): 2,3 in
- Width: 5 mm
- Width (in): 0,197 in
- Depth: 64 mm
- Depth (in): 2,52 in
- Strip length from: 8 mm
- Strip length to: 9 mm
- Strip length (in): 0,33 in
