WALSIN WF25P1001FTL High Power Chip Resistor
The resistors are high power, surface-mount chip resistors constructed with a ceramic aluminum oxide body, laser-trimmed for precision, and coated for protection. They offer a high power rating of up to 2W with a compact 2512 size, making them suitable for power supplies, digital meters, automotive applications, and DC-DC converters. Compliant with RoHS, lead-free, and flame retardant, these resistors feature reliable soldering, withstands high temperatures from -55°C to +155°C, and provides stable resistance with tolerances of ±1% or ±5%. They are ideal for space-constrained, high-reliability electronic circuits.
WALSIN WF25P1001FTL High Power Chip Resistor Specifications:
- Series: WF25P (2512), WF20P (2010), WF12P (1206)
- Resistance Range: 00, 12 ~ 1MQ
- Resistance Tolerance: ±1%, ±5%
- Resistance Temperature Coefficient: +100 ppm/°C
- Max. Dissipation at 70°C: 2W (WF25P), 1W (WF20P), 0.5W (WF12P)
- Max. Operation Voltage: 300V (WF25P), 200V (WF20P & WF12P)
- Max. Overload Voltage: 500V (WF25P), 400V (WF20P & WF12P)
- Operating Temperature Range: -55°C to +155°C
- Mechanical Size: WF25P 6.3 x 3.1 mm, WF20P 5.0 x 2.5 mm, WF12P 3.1 x 1.6 mm
- Peak Current: 25A (WF25P), 17.5A (WF20P), 12.5A (WF12P)
- Resistance Max: 20mΩ
- Soldering Condition: Immersed in 260°C solder bath for 10 seconds, or solderability testing at 235°C for 2 seconds
- Marking: Resistance value in four digits (WF25P, WF20P) or three digits (WF12P), e.g., 102=1kΩ
- REel/ Tape Dimensions: WF12 8mm width, 5,000 pcs/reel; WF25/WF20 12mm width, 4,000 pcs/reel
Buy the Walsin 1001 – Reliable Power Chip Resistors for Industrial Applications
Order Walsin high power chip resistors today and ensure your electronic projects benefit from their compact size, high reliability, and stable performance. Ideal for demanding industrial, automotive, and digital applications, these resistors handle significant power loads with precision and durability. With RoHS compliance and lead-free construction, they meet strict environmental standards. Easy to mount and solder, they are perfect for automated assembly lines, offering long-term consistency. Enhance your electronic designs by purchasing these reliable, high-quality resistors online now for fast delivery and professional support.
Buy Walsin WF25P resistors now and experience unmatched reliability and performance in your power supply and industrial circuits.
Frequently Asked Questions
Where can I buy WALSIN WF25P1001FTL?
You can click on the BUY or RFQ button to purchase WF25P1001FTL from an authorized WALSIN distributor.
How do I troubleshoot issues or seek technical support for part WF25P1001FTL?
You can download the WF25P1001FTL datasheet or visit the WALSIN website for support.
Who is the manufacturer of WF25P1001FTL?
WALSIN
