WALSIN WR04X3001FTL Thick Film Chip Resistor
High reliability and stability surface mount thick film chip resistors constructed with a ceramic body and metal electrodes, offering precise resistance values with laser trimming, RoHS compliance, and lead-free features. Available in sizes 1206, 0805, 0603, and 0402, these resistors serve applications in consumer electronics, computing, and telecommunications. They meet IEC and JIS standards, feature excellent solderability, and are suitable for automatic placement with robust construction for long-term durability under various environmental conditions.
WALSIN WR04X3001FTL Thick Film Chip Resistor Specifications:
- Size options: 1206 (3216), 0805 (2012), 0603 (1608), 0402 (1005)
- Resistance range: 1Ω to 10 MΩ (+5% tolerance)
- Resistance tolerance: ±5% (E24 series), ±1% (E96 series)
- Temperature Coefficient of Resistance: ±100 ppm/°C for >10 MΩ, ±200 to +400 ppm/°C for <10 Ω
- Max dissipation: 1/4W at 70°C for WR12, 1/8W for WRO8, 1/16W for WRO6 and WRO4
- Rated voltage: 200V for WR12, 150V for WRO8, 75V for WRO6, 50V for WRO4
- Overload voltage: 400V for WR12, 300V WRO8, 150V for WRO6, 100V for WRO4
- Climatic category: 55/155/56
- Dimensions: Length 3.10 mm (WR12), 2.00 mm (WRO8), 1.60 mm (WRO6), 1.00 mm (WRO4); width and thickness scaled accordingly
- Marking: 3-digit (+5%) or 4-digit (+1%) resistance code on surface, per series
- Temperature range: -55°C to +155°C
- Storage conditions: 5°C to 40°C, 20-70% humidity, avoid corrosive environments, handle with care
- Soldering conditions: Reflow at 235°C for 2 seconds, immersion in 260°C for 10 seconds
- Compliance: RoHS, Lead-free, UL, CSA certified
- Application suitability: Consumer electronics, computers, telecom
Buy the Buy Walsin Technology Thick Film Resistors Part Number WR04X3001FTL Online
Order Walsin Technology WR04X3001FTL online today to ensure your electronic projects and manufacturing processes benefit from high reliability, precise resistance values, RoHS compliance, and robust construction. Designed for surface mounting, these resistors are ideal for consumer electronics, computing, and telecom applications. With sizes 1206, 0805, 0603, and 0402, they meet IEC and JIS standards, feature easy solderability, and are stored under optimal conditions for long shelf life. Purchase now for consistent quality and performance in your assembly line or repair work.
Get Walsin Technology WR04X3001FTL today—built for high accuracy and long-lasting durability in electronic applications.
Frequently Asked Questions
Where can I buy WALSIN WR04X3001FTL?
You can click on the BUY or RFQ button to purchase WR04X3001FTL from an authorized WALSIN distributor.
How do I troubleshoot issues or seek technical support for part WR04X3001FTL?
You can download the WR04X3001FTL datasheet or visit the WALSIN website for support.
Who is the manufacturer of WR04X3001FTL?
WALSIN
