WOODHEAD / MOLEX C18312N21 Cable Connectors
The WOODHEAD / MOLEX C18312N21 is a circular cable connector engineered for demanding industrial environments. It offers a secure and reliable connection with a robust design and high-performance characteristics. The connector supports a maximum current of 16.0A and a voltage of 250V, making it suitable for a wide range of applications. Its insulation resistance of 100 Megaohms and low contact resistance of ≤15 milliohms ensure efficient signal transmission and minimal power loss. The operating temperature range, dependent on the gasket material (NBR: -40°C to +90°C, Silicone: -40°C to +125°C), allows for versatile deployment in various climates. The connector's design incorporates features like integrated gaskets for environmental protection (IP65, IP67 available) and a choice of thread sizes (PG6-M16, PG11-G1/2”-M20) to accommodate different cable diameters. Refer to PDP 1210230229 for configured part numbers and PS-121201-001 for product specifications.
WOODHEAD / MOLEX C18312N21 Cable Connectors Specifications:
- MAX. CURRENT: 16.0A
- INSULATION RESISTANCE: 100Megaohms min.
- MAX. CONDUCTOR: 1.50mm[2] /16AWG
- MAX. VOLTAGE: 250V
- CONTACT RESISTANCE: ≤15milliohms max.
- CABLE DIAMETER RANGE: PG6-M16 : 6.00-8.00mm, PG11 - G1/2”-M20 : 8.00-10.00mm
- OPERATING TEMPERATURE (NBR GASKET): -40°C TO +90°C
- OPERATING TEMPERATURE (SILICONE): -40°C TO +125°C
- ENVIRONMENTAL: IP65 (IP67 available on request)
Buy the C18312N21 WOODHEAD / MOLEX Cable Connectors | myMectronic
Purchase the WOODHEAD / MOLEX C18312N21 securely and reliably online for your industrial needs.
Buy Now
Frequently Asked Questions
Where can I buy WOODHEAD / MOLEX C18312N21?
You can click on the BUY or RFQ button to purchase C18312N21 from an authorized WOODHEAD / MOLEX distributor.
How do I troubleshoot issues or seek technical support for part C18312N21?
You can download the C18312N21 datasheet or visit the WOODHEAD / MOLEX website for support.
Who is the manufacturer of C18312N21?
WOODHEAD / MOLEX
