WOODHEAD / MOLEX E11A06004M060 M12 Ethernet Connector
The WOODHEAD / MOLEX E11A06004M060 is a robust M12 Ethernet connector engineered for reliable data communication in industrial automation, process control, and networking applications. It features a teal TPE jacket, providing excellent flexibility and durability. The connector utilizes tinned copper conductors with a PE insulation and a gold-over-nickel plating for enhanced signal integrity and corrosion resistance. It is designed to operate within a temperature range of -50°C to +75°C and supports a maximum voltage of 300V, making it suitable for a wide range of harsh environments. The connector's construction ensures secure and dependable connectivity for critical data transfer needs.
WOODHEAD / MOLEX E11A06004M060 M12 Ethernet Connector Specifications:
- series: MIC 4P M/MP ST/ST D-CODED XM
- material_number: 130048
- engineering_no_l_mm: 6000
- cable_specification_conductor_material: Tinned Copper
- cable_specification_conductor_section: 24AWG
- cable_specification_insulation_compound: PE
- cable_specification_insulation_diameter: 0.99mm
- cable_specification_jacket_compound: TPE
- cable_specification_jacket_color: Teal
- cable_specification_jacket_diameter: 5.58mm
- cable_specification_temperature_rating: -50°C to +75°C
- cable_specification_voltage_rating_max: 300V
- cable_specification_color_coding: White/Orange, White/Green
- length_tolerances_over_up_to_and_including: +19
- length_tolerances_over_915: +45
- length_tolerances_over_1830: +56
- length_tolerances_over_3660: +89
- length_tolerances_over_7320: +165
- length_tolerances_over_14640: +317
- length_tolerances_over_30500: +610
- length_tolerances_over_30500_2: +2% of Length
Buy the E11A06004M060 WOODHEAD / MOLEX M12 Ethernet Connector | myMectronic
Purchase the WOODHEAD / MOLEX E11A06004M060 M12 Ethernet Connector securely and conveniently online.
Buy Now
Frequently Asked Questions
Where can I buy WOODHEAD / MOLEX E11A06004M060?
You can click on the BUY or RFQ button to purchase E11A06004M060 from an authorized WOODHEAD / MOLEX distributor.
How do I troubleshoot issues or seek technical support for part E11A06004M060?
You can download the E11A06004M060 datasheet or visit the WOODHEAD / MOLEX website for support.
Who is the manufacturer of E11A06004M060?
WOODHEAD / MOLEX
