WURTH ELEKTRONIK 150120VS75000 SMD Chip LED
The WURTH ELEKTRONIK 150120VS75000 is a top-view, mono-color waterclear SMD chip LED designed for general electronic equipment. It emits bright green light with a peak wavelength of 572nm and a dominant wavelength of 570nm. The LED offers a luminous intensity ranging from 12 to 40 mcd and a forward voltage between 2.0 and 2.4V. It is not intended for use in safety-critical applications without proper evaluation and agreement. Operating temperature range is -40°C to +85°C.
WURTH ELEKTRONIK 150120VS75000 SMD Chip LED Specifications:
- Optical Properties: Bright Green
- Lens Type: Chip LED
- Power Dissipation: 72 mW
- Peak Forward Current: 100 mA
- Continuous Forward Current: 30 mA
- Reverse Voltage: 5 V
- ESD Threshold HBM: 2000 V
- Operating Temperature: -40°C to +85°C
- Storage Temperature: -40°C to +85°C
- Moisture Sensitivity Level: 3
- Peak Wavelength: 572 nm
- Dominant Wavelength: 570 nm
- Luminous Intensity: 12-40 mcd
- Forward Voltage: 2.0-2.4 V
- Spectral Bandwidth: 15 nm
- Reverse Current: ≤10 μA
- Viewing Angle: 140°
Buy the 150120VS75000 WURTH ELEKTRONIK SMD Chip LED | myMectronic
Securely purchase the WURTH ELEKTRONIK 150120VS75000 online for reliable component delivery.
Buy Now
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 150120VS75000?
You can click on the BUY or RFQ button to purchase 150120VS75000 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 150120VS75000?
You can download the 150120VS75000 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 150120VS75000?
WURTH ELEKTRONIK
