WURTH ELEKTRONIK 173010378 Fixed Step Down Power Module
The WURTH ELEKTRONIK FDSM series of MagI[3] C Power Modules is a fully integrated dc/dc power supply designed for point-of-load applications and replacement of linear regulators. It features a fixed output voltage, integrated components, and high efficiency, reducing power dissipation and simplifying assembly. The module is pin compatible with common 78xx linear regulator series and offers features like current mode control, thermal shutdown, and short circuit protection, making it suitable for various industrial applications.
WURTH ELEKTRONIK 173010378 Fixed Step Down Power Module Specifications:
- Input Voltage Range: 7 to 28V
- Output Voltage: 3.3 or 5V
- Output Current: Up to 1A
- Peak Efficiency: Up to 93%
- Output Voltage Ripple (3.3V): Typ. 15mV at 1A load
- Output Voltage Ripple (5V): Typ. 25mV at 1A load
- Output Voltage Accuracy: 3.5% typ.
- Switching Frequency: 300 kHz
- Ambient Operating Temperature Range: -40°C to 85°C
- Package Material: UL94V-0
- Compliance: RoHS & REACH compliant
- EN55022 Compliance: Class B
- Thermal Shutdown Temperature: 165°C
- Junction-to-Ambient Thermal Resistance: 77 °C/W
- Weight: 2.0g
