WURTH ELEKTRONIK 430156095736 THT Relay Module
The Wurth Elektronik 430156095736 is a THT relay module designed for integration into printed circuit boards. It offers reliable switching capabilities with a stainless steel cover, LCP stem and frame, and a brass terminal with tin plating. This component is intended for general electronics applications and requires careful safety evaluation before use in critical systems such as aerospace, automotive, or medical devices. Refer to the datasheet for detailed technical specifications and operating conditions.
WURTH ELEKTRONIK 430156095736 THT Relay Module Specifications:
- Rating: 50mA, 12VDC
- Contact Resistance: Initial: 100mOHM max., After Life Test: 2OHM max.
- Insulation Resistance: min. 100MOHM at 500VDC
- Dielectric Strength: 250VAC for 1 minute
- Stroke: 0.25 + 0.2 mm / - 0.1 mm
- Cover: Stainless Steel
- Stem: LCP UL 94V-0
- Frame: LCP UL 94V-0, color Black
- Contact: Stainless Steel with silver cladding
- Terminal: Brass with tin plating
- Terminal in THT version: Yes
- Wave Soldering: 260°C 10sec. max
- Hand Soldering: 350°C for 3 sec. max
- Storage Condition: -40°C ~ +85°C
- Operation Condition: -40°C ~ +85°C
- Compliance: Lead Free, ROHS, Reach
Buy the 430156095736 WURTH ELEKTRONIK THT Relay Module | myMectronic
Purchase the Wurth Elektronik 430156095736 THT Relay Module securely online for your electronics projects.
Buy Now
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 430156095736?
You can click on the BUY or RFQ button to purchase 430156095736 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 430156095736?
You can download the 430156095736 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 430156095736?
WURTH ELEKTRONIK
