WURTH ELEKTRONIK 430186050716 THT Switch Terminal Block
The Wurth Elektronik 430186050716 is a THT (Through-Hole Technology) switch terminal block engineered for robust and dependable connections in a wide range of electronic applications. Constructed with stainless steel and featuring tin plating, this terminal block offers excellent conductivity and resistance to corrosion. It is designed for use in general electronics equipment and is suitable for applications requiring secure and reliable connections. Before incorporating this component into critical systems like aerospace or medical devices, it's essential to obtain written approval from Wurth Elektronik to ensure suitability and safety.
WURTH ELEKTRONIK 430186050716 THT Switch Terminal Block Specifications:
- Rating: 50mA, 12VDC
- Contact Resistance: Initial: 100mOHM max., After Life Test: 2OHM max.
- Insulation Resistance: min. 100MOHM at 500VDC
- Dielectric Strength: 250VAC for 1 minute
- Stroke: 0.25 + 0.2 mm / - 0.1 mm
- Cover Material: Stainless Steel
- Stem Material: LCP UL 94V-0
- Frame Material: LCP UL 94V-0, color Black
- Contact Material: Stainless Steel with silver cladding
- Terminal Material: Brass with tin plating
- Wave Soldering: 260°C 10sec. max
- Hand Soldering: under 350°C for 3 sec. max
- Storage Temperature: -40°C ~ +85°C
- Operation Temperature: -40°C ~ +85°C
- Compliance: Lead Free, ROHS, Reach
Buy the 430186050716 WURTH ELEKTRONIK THT Switch Terminal Block | myMectronic
Purchase the Wurth Elektronik 430186050716 THT Switch Terminal Block securely and conveniently online.
Buy Now
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 430186050716?
You can click on the BUY or RFQ button to purchase 430186050716 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 430186050716?
You can download the 430186050716 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 430186050716?
WURTH ELEKTRONIK
