WURTH ELEKTRONIK 62101421021 Smart Pin Header
This SMT straight dual pin header features 1.27mm pitch with 14 pins, gold-plated contact material, and a black insulator. Designed for reliable electrical connections, it supports operating temperatures from -40°C to +105°C, and complies with RoHS standards. Suitable for high-density electronic assemblies, it offers excellent mechanical durability along with maximum coplanarity of 100 μm. The header is ideal for compact electronic circuits requiring precise pin spacing, robust contact resistance, and efficient soldering in various manufacturing environments.
WURTH ELEKTRONIK 62101421021 Smart Pin Header Specifications:
- Pitch: 1.27 mm
- Pins: 14
- Pin to Pin (Middle): 7.62 mm
- Length: 8.89 mm
- Contact Material: Copper Alloy
- Contact Plating: Gold
- Insulator Color: Black
- Temperature Range: -40°C to +105°C
- Rated Current: 1 A max.
- Working Voltage: 100 VAC
- Withstanding Voltage: 500 VAC for 1 minute
- Contact Resistance: 20 mΩ max.
- Insulation Resistance: 1000 MΩ min.
- RoHS Compliant
- Material: PAST (Polyamide based insulator)
- Flammability Rating: UL94 V-0
- Packging Unit: 65
Buy the Wirth Elektronik Series SMT Dual Pin Header: 62101421021
Order the Wirth Elektronik 62101421021 dual pin header online today to ensure secure, precise, and durable connections in your electronic assemblies. This 1.27mm pitch SMT header with 14 gold-plated contacts offers high reliability, excellent electrical performance, and RoHS compliance. Featuring a compact design, it supports temperatures from -40°C to +105°C, and its robust construction guarantees long-lasting durability in demanding environments. Simplify your manufacturing process by purchasing this quality connector online now and enhance your device’s performance effortlessly.
Buy Wirth Elektronik 62101421021 now and experience unmatched reliability and high-density connection performance for your electronic projects.
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 62101421021?
You can click on the BUY or RFQ button to purchase 62101421021 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 62101421021?
You can download the 62101421021 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 62101421021?
WURTH ELEKTRONIK
