WURTH ELEKTRONIK 744340300030 High Current Flat Inductor
The Würth Elektronik WE-HCM series is a family of SMT shielded power inductors designed for high-current applications. These inductors feature a compact, flat design, making them ideal for space-constrained designs. They offer low DC resistance and a high self-resonant frequency, ensuring efficient performance in power management circuits, DC-DC converters, and filtering applications. The 744340300030 model is RoHS compliant and REACH conform, meeting environmental standards. Operating temperature ranges from -40°C to +125°C, ensuring reliable performance in a wide range of environments. The component is marked with a date code for traceability.
WURTH ELEKTRONIK 744340300030 High Current Flat Inductor Specifications:
- Inductance L: 0.03 µH ±15%
- Rated Inductance LR: 0.029 µH typ.
- Rated Current IR: 27 A max.
- Saturation Current ISAT: 44 A typ.
- DC Resistance RDC: 0.27 mΩ ±15%
- Self Resonant Frequency fres: 170 MHz typ.
- Ambient Temperature: -40 up to +85 °C
- Operating Temperature: -40 up to +125 °C
- Storage Conditions: in original packaging < 40 °C ; < 75 % RH
- Moisture Sensitivity Level (MSL): 1
- Packaging Quantity: 2000
- Material: Polystyrene
Buy the 744340300030 WURTH ELEKTRONIK High Current Flat Inductor | myMectronic
Purchase the Würth Elektronik 744340300030 SMT shielded power inductor securely and conveniently online.
Buy Now
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 744340300030?
You can click on the BUY or RFQ button to purchase 744340300030 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 744340300030?
You can download the 744340300030 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 744340300030?
WURTH ELEKTRONIK
