WURTH ELEKTRONIK 74438334012 Power Inductor
The WE-MAPI SMD Power Inductor by Wirth Elektronik is a compact 3012 size electronic component designed for general electronic equipment. It offers an inductance of 1.2 µH with a tolerance of ±20% at 100 kHz and 10 mA. Rated for a maximum current of 2.65 A, it features a DC resistance of 66.0 mΩ at 20°C, with a self-resonant frequency of 66 MHz. This inductor's temperature ratings span from -40°C to +125°C, ensuring reliable performance in various applications, including power management, filtering, and inductive circuits.
WURTH ELEKTRONIK 74438334012 Power Inductor Specifications:
- Size: 3012
- Inductance: 1.2 µH
- Tolerance: ±20%
- Test Frequency: 100 kHz
- Rated Current: 2.65 A max.
- Saturation Current: 6.0 A typ.
- DC Resistance @20°C: 66.0 mΩ max.
- Self Resonant Frequency: 66 MHz
- Operating Temperature Range: -40°C to +125°C
- Storage Temperature: -20°C to +40°C
- Material: Magnetic core with ferrite core
- Compliance: RoHS & REACh
- Application: Power filtering, inductive circuits, power management
Buy the Wirth Elektronik 74438334012 – Reliable Power Inductor for Industrial Applications
Experience reliable power management with the Wirth Elektronik Power Inductor. Designed for general electronic equipment, this 3012 component offers 1.2 µH inductance, up to 2.65 A rated current, and robust temperature ratings up to 125°C. Its compact size and compliance with RoHS & REACh standards make it ideal for power filtering, inductive circuits, and industrial applications. Order online now to ensure seamless integration into your electronic designs—built for durability, accuracy, and high performance in demanding environments.
Get Wirth Elektronik 74438334012 today—built for precision, high current capacity and long-lasting durability in electronic circuits.
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 74438334012?
You can click on the BUY or RFQ button to purchase 74438334012 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 74438334012?
You can download the 74438334012 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 74438334012?
WURTH ELEKTRONIK
