WURTH ELEKTRONIK 74476401 Wire Wound Inductor
This WURTH ELEKTRONIK SMD Wire Wound Inductor is designed for general electronic equipment, featuring a size of 1210, inductance of 1.0 μH with +10% tolerance, and rated current of 400 mA. It operates within ambient temperatures of -40°C to +85°C and a maximum temperature of 105°C, ensuring reliable performance in electronics applications. Suitable for signal filtering, power supplies, and inductive circuits, it adheres to RoHS and REACH standards, offering robust electrical properties, self-resonant frequency of 120 MHz, and a Q-factor of 30 min at 7.96 MHz, making it ideal for various industrial electronic designs.
WURTH ELEKTRONIK 74476401 Wire Wound Inductor Specifications:
- Size: 1210
- Inductance: 1.0 μH ±10%
- Rated Current: 400 mA
- DC Resistance: 0.07 Ω
- Self Resonant Frequency: 120 MHz
- Q-factor: ≥30 at 7.96 MHz
- Operating Temperature: -40°C to +105°C
- Storage Temperature: -20°C to +40°C; 75% RH max
- Ambient Temperature: -40°C to +85°C
- Certifications: RoHS, REACH compliant
- Package: Tape and reel, size: 1210
- Max Reflow Profile: Peak temperature 245°C, soak time 60-150 sec
- Soldering: Use approved reflow profile, max ramp-up 3°C/sec
- Construction: Wire wound magnetic core
Buy the WURTH ELEKTRONIK 74476401 – Reliable Inductor for Industrial Applications
Purchase the WURTH ELEKTRONIK Wire Wound Inductor online today and enjoy high reliability in your electronic designs. With a compact 1210 size and inductance of 1.0 μH, it offers a rated current of 400 mA and operates safely up to 105°C, making it suitable for power supplies, signal filtering, and inductive circuits. This RoHS and REACH compliant component ensures excellent electrical performance with a self-resonant frequency of 120 MHz and a Q-factor of at least 30 at 7.96 MHz. Order now for consistent quality and performance in your electronic projects.
Get WURTH ELEKTRONIK 74476401 today—built for precision and long-lasting durability in power filtering and inductive circuits.
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 74476401?
You can click on the BUY or RFQ button to purchase 74476401 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 74476401?
You can download the 74476401 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 74476401?
WURTH ELEKTRONIK
