WURTH ELEKTRONIK 744764112 Wire Wound Inductor
This WURTH ELEKTRONIK SMD Wire Wound Inductor is designed for general electronic equipment, offering a 12 uH inductance with a +10% tolerance, rated at 140 mA, and a maximum DC resistance of 25 Q at 20°C. It operates efficiently within -40°C to +105°C, ensuring reliable performance in electronic circuits requiring inductors with high self-resonant frequency up to 10 MHz. Suitable for various applications, it complies with RoHS and REACh standards, and features precise dimensions and markings for easy identification and integration in complex assemblies.
WURTH ELEKTRONIK 744764112 Wire Wound Inductor Specifications:
- Inductance: 12 uH ±10%
- Rated Current: 140 mA at 20°C
- DC Resistance: 25 Q max. @ 20°C
- Self Resonant Frequency: 10 MHz typ.
- Q-factor: 30 min. at 2.52 MHz
- Operating Temperature: -40°C to +105°C
- Storage Temperature: -20°C to +40°C; 75% RH max.
- Ambient Temperature: -40°C to +85°C
- Power Ratings based on application
- Size: 1210 (imperial size code), physical dimensions compliant with industry standards
- Packaging: Tape and reel, with specified tolerances
- Standards: RoHS and REACh compliant
- Markings: 120 (Inductance Code), reference on drawing
- Max. Ramp Up Rate: 3°C/sec, Max Ramp Down Rate: 6°C/sec
- Soldering Profile: As per IPC/JEDEC J-STD-020D
Buy the Buy WURTH ELEKTRONIK Inductor Part Number 744764112 Online
Discover the ease of acquiring the high-quality WURTH ELEKTRONIK Wire Wound Inductor online. Designed for general electronic applications, the 12 uH inductor with a rated 140 mA current ensures dependable circuit performance. It features low DC resistance, high self-resonant frequency up to 10 MHz, and complies with RoHS and REACh standards. Perfect for circuit design, testing, and replacement, ordering online simplifies procurement, provides fast delivery, and guarantees authentic, compliant components suitable for demanding electronic systems in various industries.
Order your WURTH ELEKTRONIK 12 uH Wire Wound Inductor PartNumber 744764112 today and ensure your electronic circuits perform reliably at high frequencies.
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 744764112?
You can click on the BUY or RFQ button to purchase 744764112 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 744764112?
You can download the 744764112 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 744764112?
WURTH ELEKTRONIK
