WURTH ELEKTRONIK 74476630 SMD Wire Wound Inductor
The Wurth Elektronik WE-GF SMD Wire Wound Inductor is a compact, high-performance component designed for electronic circuits requiring stable inductance. With a size of 1812 and inductance of 1000 uH rated at 0.252 MHz with a +10% tolerance, it offers low DC resistance of 50 Q at 20°C and a self-resonant frequency around 25 MHz. Suitable for applications demanding high reliability, it features a maximum rated current of 30 mA and operates within a temperature range of -40°C to +105°C. Proper handling and soldering according to detailed profiles ensure optimal performance and safety compliance.
WURTH ELEKTRONIK 74476630 SMD Wire Wound Inductor Specifications:
- Inductance: 1000 uH, Tolerance: +10%
- Rated current: 30 mA maximum at 20°C
- DC Resistance: 50 Q maximum at 20°C
- Self resonant frequency: 25 MHz typical
- Operating temperature: -40°C to +105°C
- Storage temperature: -20°C to +40°C, 75% RH max
- Size: 1812 (mm)
- Ambient temperature: -40°C to +85°C
- Soldering profile: Reflow max temperature 245°C, peak time 20-30s
- Max. ramp-up rate: 3°C/sec, ramp-down rate: 6°C/sec
- Max. lead preheat: 150°C min, 200°C max, time: 60-120 sec
Buy the Wurth Elektronik Series WE-GF Inductor: 1000 uH - Part 74476630
Purchase the Wurth Elektronik SMD Wire Wound Inductor number 74476630 online today to secure a high-quality, reliable component suitable for demanding electronic applications. This 1812 size inductor featuring 1000 uH inductance, low resistance, and operating temperature range from -40°C to +105°C ensures optimal circuit performance and durability. Its compact design and precise electrical characteristics make it ideal for various industrial and consumer electronics, providing dependable functionality and easy integration into your designs. Boost your project’s reliability—buy now for fast delivery and top-quality performance.
Order your Wurth Elektronik Series WE-GF inductance component number 74476630 today and ensure your electronic projects benefit from reliable, high-performance inductors.
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 74476630?
You can click on the BUY or RFQ button to purchase 74476630 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 74476630?
You can download the 74476630 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 74476630?
WURTH ELEKTRONIK
