WURTH ELEKTRONIK 7466313R High-Current SMD Connector
The Wurth Elektronik REDCUBE SMD right angled connector with Pins WP-SMRA is designed for precise surface mounting applications in electronics. Constructed from high-quality brass with a tin surface, it offers reliable electrical connectivity and mechanical stability. The connector supports a rated current of 50 A at 20°C, with a maximum operating temperature of up to +150°C. It features a compact design suitable for SMT processes, with recommended soldering parameters and adherence to JEDEC standards for quality and durability. Ideal for industrial and electronic equipment requiring robust, high-current connections.
WURTH ELEKTRONIK 7466313R High-Current SMD Connector Specifications:
- Material: Brass with Tin surface
- Rated Current: 50 A at 20°C
- Maximum Operating Temperature: +150°C
- Dimensions: Custom designed for SMT applications, details in datasheet
- Solder Cream Thickness: 120 μm
- Tightening Torque: 0.4 Nm
- Preheat Temperature: 150°C to 200°C
- Preheat Time: 60-120 seconds
- Max. Ramp Up Rate: 3°C/second
- Max. Ramp Down Rate: 6°C/second
- Operating Temperature Range: -55°C to +150°C
- Packaging: Tape and Reel, 7000 units per reel
- Conforms to IEC 60286-3 standard for packaging
- Application: SMT surface mounting in industrial electronics
- Reliable electrical and mechanical connection for high-current applications
- Compatible with reflow soldering methods as per IPC/JEDEC standards
Buy the Wurth Elektronik 7466313R – Reliable High-Current Connectors for Industrial Applications
Secure your industrial electronics with the reliable high-current Wurth Elektronik connector. Designed for SMT mounting, it supports up to 50 A at 20°C, with a maximum temperature of +150°C. Manufactured from durable brass and tin, it provides excellent electrical conductivity and mechanical stability. Equipped with precise soldering specifications, including a 120 μm solder cream thickness and recommended reflow profile, it ensures secure, long-lasting connections in demanding environments. Order online now for fast delivery and trusted quality in your electronics assembly.
Order your Wurth Elektronik Series 7466313R connector today and ensure robust, high-current connections for your industrial products.
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 7466313R?
You can click on the BUY or RFQ button to purchase 7466313R from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 7466313R?
You can download the 7466313R datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 7466313R?
WURTH ELEKTRONIK
