WURTH ELEKTRONIK 820513001 Disk Varistor
The WE-VD Disk Varistor by Wurth Elektronik is a high-quality, 10mm SMD protective component designed for surge suppression and voltage clamping in electronic circuits. Certified with RoHS, REACh, and VDE approvals, it offers reliable performance with a maximum AC operating voltage of 30V and a max DC voltage of 38V. It absorbs energy up to 6J and features a nominal discharge current of 0.25kA, ensuring safe, efficient operation in various electronic applications. The varistor operates within -40°C to +85°C, with storage instructions to ensure longevity and performance integrity.
WURTH ELEKTRONIK 820513001 Disk Varistor Specifications:
- Dimensions: 10mm diameter
- Maximum AC Operating Voltage: 30V
- Maximum DC Operating Voltage: 38V
- Energy Absorption: 6 Joules
- Clamping Voltage: 93V at 5A
- Peak Pulse Current: 500A
- Nominal Discharge Current: 0.25kA
- Operating Temperature: -40°C to +85°C
- Storage Temperature: -40°C to +75% RH
- Certifications: RoHS, REACh, VDE, UL1449
- Material: Metal oxide (varistor ceramic)
- Soldering Profile: Compatible with wave soldering, Pb-Free, Sn-Pb options
- Packaging: Reel in carton per IEC 60286-2:2015
Buy the Buy Wurth Elektronik Disk Varistor Part Number 820513001 Online
Order the Wurth Elektronik Disk Varistor online today to ensure your electronic circuits are protected against voltage spikes and surges. This 10mm component offers energy absorption up to 6 joules, withstands voltages up to 38V DC and 30V AC, and operates efficiently in temperature ranges from -40°C to +85°C. Its certified RoHS, REACh, and VDE approvals make it a dependable choice for various applications, including surge suppression, circuit protection, and voltage clamping. Secure your electronic device's longevity by purchasing this reliable varistor online now.
Buy Wurth Elektronik 820513001 now and experience unmatched surge protection and reliable circuit safeguarding in electronic equipment.
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 820513001?
You can click on the BUY or RFQ button to purchase 820513001 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 820513001?
You can download the 820513001 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 820513001?
WURTH ELEKTRONIK
