WURTH ELEKTRONIK 860040274005 Aluminum Capacitor
Wurth Elektronik's WCAP-ATUL aluminum electrolytic capacitor, designed for electronic applications requiring high reliability and stability, offers a capacitance of 680 µF rated at 10 V. It features a voltage rating up to 10 V, operating temperature from -40°C to +105°C, load life of 6000 hours at +105°C, and complies with RoHS and REACH standards. The capacitor includes a vent for pressure relief, robust construction with PVC sleeve, and is suitable for various electronic circuits demanding stable performance and safety. Ideal for power supplies, filtering, and industrial electronics where durability is essential.
WURTH ELEKTRONIK 860040274005 Aluminum Capacitor Specifications:
- Capacitance: 680 µF ±20%
- Rated Voltage: 10 V DC
- Leakage Current: 68.0 μA max after 2 min.
- Dissipation Factor: 0.19% at 120 Hz
- Ripple Current: 770 mA max at 105°C and 100kHz
- Impedance: 0.096 Ω max at 20°C and 100kHz
- Operating Temperature: -40°C to +105°C
- Load Life: 6000 hours at +105°C and 10 V
- Storage Conditions: 35°C, <45% RH
- Soldering: Wave soldering with specific temperature profiles
- Material: Aluminum with PVC sleeve
- Dimensions: Size 8.0 x 16.0 mm
- Compliance: RoHS & REACH
- Design: Pressure relief vent, anti-deformation sleeve
Buy the Wurth Elektronik 860040274005 – Reliable Aluminum Electrolytic Capacitor for Industrial Applications
Purchase Wurth Elektronik aluminum electrolytic capacitor now to ensure your electronic systems are built with high-quality, durable components. With 680 µF capacitance, 10 V voltage rating, and operation from -40°C to +105°C, this capacitor guarantees stability and longevity in industrial and electronic circuits. Its robust design includes a pressure vent and PVC sleeve for safety, making it suitable for power supplies, filtering, and automation systems. Order online today and benefit from fast delivery, trusted quality, and technical support for your critical applications.
Buy Wurth Elektronik 860040274005 now and experience unmatched reliability and performance in power supply and filtering applications.
