WURTH ELEKTRONIK 860130375008 Aluminum Electrolytic Capacitor
Würth Elektronik's WCAP-ATET Aluminum Electrolytic Capacitors are designed for general electronic equipment, offering high temperature tolerance up to +125°C, with a lifespan of 2000 hours at 125°C/16 V. They have a capacitance of 1000μF rated at 16 V DC, suitable for applications requiring reliable power filtering and energy storage. These capacitors feature a vent for pressure relief, are RoHS and REACH compliant, and come with detailed soldering and handling instructions for optimal performance and safety in various industrial and electronic environments.
WURTH ELEKTRONIK 860130375008 Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 1000μF
- Rated Voltage: 16 V DC
- Temperature Range: -40°C to +125°C
- Lifespan: 2000 h @ +125°C / 16 V
- Vent for pressure relief
- RoHS & REACH compliant
- Size: 10.0 x 25.0 mm
- Leakage Current: Max 160mA after t min
- Dissipation Factor: Max 15% at 120Hz
- Ripple Current: Max 950mA @ 125°C
- Storage Conditions: 5°C to 35°C, <75% RH
- Wave Soldering: Authorized with careful temperature control
- Polarity: Marked with shorter lead, negative terminal indicated by color band
- Operating Temperature: -40°C to +125°C
Buy the Wurth Series Aluminum Electrolytic Capacitor: 860130375008
Purchase your Aluminum Electrolytic Capacitor online now to benefit from rapid delivery and factory-direct prices. Our high-quality capacitors, rated at 16 V and 1000μF, are ideal for power filtering and energy storage in a variety of electronic and industrial applications. Featuring a pressure vent for safety, they are RoHS and REACH compliant, ensuring environmental safety and performance. Easy to install with precise dimensions of 10.0 x 25.0 mm, these capacitors deliver excellent reliability at elevated temperatures up to 125°C. Order today and enhance your project’s stability with trusted components.
Order your Wurth Series Aluminum Electrolytic Capacitor today and give your electronic projects the dependable quality they deserve, ensuring high temperature tolerance and long-term reliability.
