WURTH ELEKTRONIK 861111483001 Electrolytic Capacitor
The WURTH ELEKTRONIK WCAP-AIL5 Aluminum Electrolytic Capacitor is designed for electronic equipment, offering a capacitance of 33 μF with a rated voltage of 450 V DC. It features a temperature range of -25°C to +105°C, with a load life of 2000 hours at 105°C and 450 V. Designed with safety in mind, it includes a vent for pressure relief, Polarity markings, and is RoHS & REACH compliant. Suitable for applications requiring high reliability, this capacitor provides stable electrical properties and robust construction suitable for industrial uses.
WURTH ELEKTRONIK 861111483001 Electrolytic Capacitor Specifications:
- Capacitance: 33 μF ±20%
- Rated Voltage: 450 V DC max.
- Operating Temperature: -25°C to +105°C
- Load Life: 2000 hours at 105°C and 450 V
- Leakage Current: 297 pA max after 5 min
- Dissipation factor: 20% at 120Hz
- Ripple Current: max. 240 mA at 120Hz and 105°C
- Dimensions: 22.0 x 21.0 mm
- Polarity markings: Negative terminal marked with a color band and minus signs
- Storage Conditions: 5°C to 35°C, <75% RH
- Soldering: Wave and hand soldering compatible with specified temperature profiles
- Safety Features: Pressure vent for internal pressure release, overvoltage and polarity protection
- Compliance: RoHS & REACH
- Application: Suitable for electronic equipment demanding high safety and reliability
- Design: Aluminum case, PVC sleeve for insulation, with pressure relief vent
- Temperature Range: -25°C to +105°C
Buy the Buy WURTH ELEKTRONIK Aluminum Electrolytic Capacitor Part Number 861111483001 Online
Secure your electronic projects with the trusted WURTH ELEKTRONIK Aluminum Electrolytic Capacitor. Featuring 33 microfarads at 450 volts, it offers exceptional stability, a long load life of 2000 hours at 105°C, and a robust design with pressure relief vent. Ideal for industrial, automation, and power supply applications, this capacitor ensures safe operation, excellent electrical properties, and compliance with RoHS and REACH standards. Purchase online today for reliable performance in demanding electronic environments.
Buy WURTH ELEKTRONIK 861111483001 now and experience unmatched reliability and performance in high-capacity industrial electronics.
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 861111483001?
You can click on the BUY or RFQ button to purchase 861111483001 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 861111483001?
You can download the 861111483001 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 861111483001?
WURTH ELEKTRONIK
