WURTH ELEKTRONIK 861111483004 Aluminum Electrolytic Capacitor
Würth Elektronik's WCAP-AIL5 Aluminum Electrolytic Capacitors are designed for electronic equipment requiring reliable power filtering and energy storage. These capacitors operate from -25 °C to +105 °C, with a capacitance of 68 µF ±20% rated at 450 V (DC). They feature a vent to prevent explosion, are RoHS compliant, and adhere to safety standards. Suitable for industrial applications, they ensure stable performance under high temperature, ripple current, and load cycles, making them ideal for power supply smoothing and filtering in electronic circuits.
WURTH ELEKTRONIK 861111483004 Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 68 µF ±20%
- Rated Voltage: 450 V (DC)
- Operating Temperature Range: -25°C to +105°C
- Leakage Current after 5 min: Max 612 pA
- Dissipation Factor at 120Hz: 20% max.
- Ripple Current: 510 mA at 120Hz and 105°C
- Size: 22.0 x 26.0 mm
- Vent: Pressure relief vent for safety
- Storage Conditions: 5°C-35°C, <75% RH
- Soldering: Wave soldering from the PCB's reverse side, detailed process in datasheet.
- Certification: RoHS & REACH compliant
Buy the Buy Würth Elektronik Aluminum Electrolytic Capacitors Part Number 861111483004 Online
Purchase the Würth Elektronik WCAP-AIL5 Aluminum Electrolytic Capacitor online today for high-performance power filtering solutions. With a capacitance of 68 µF rated at 450 V DC, it offers excellent reliability across a temperature range of -25°C to +105°C. Designed with safety features like a pressure relief vent, RoHS compliance, and proven durability, this capacitor is ideal for industrial and electronic applications requiring stable operation under load. Buy now to improve your power circuit’s stability and longevity.
Order your Würth Elektronik WCAP-AIL5 Aluminum Electrolytic Capacitor today and ensure high reliability in power supply filtering and energy storage applications.
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 861111483004?
You can click on the BUY or RFQ button to purchase 861111483004 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 861111483004?
You can download the 861111483004 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 861111483004?
WURTH ELEKTRONIK
