WURTH ELEKTRONIK 865250340001 Electrolytic Capacitor
Aluminum electrolytic capacitor designed for electronic equipment, with a capacitance of 3.3 UF at 120Hz, rated voltage of 16V, and operating temperature from -40°C to +85°C. The device features a storage condition of 35°C and <45% RH, with a load life of 2000 hours at +85°C and 16V. It includes a vent for pressure relief, has established safety and handling warnings, and complies with RoHS and REACH standards. Suitable for applications requiring high reliability and long service life in electronic circuits with moderate voltage and temperature conditions.
WURTH ELEKTRONIK 865250340001 Electrolytic Capacitor Specifications:
- Capacitance: 3.3 UF at 120Hz
- Rated Voltage: 16 V
- Operating Temperature Range: -40°C to +85°C
- Life Expectancy: 2000 hours at +85°C and 16V
- Storage Conditions: 35°C, <45% RH
- Leakage Current: 10 pA max after 2 min
- Dissipation Factor: 17 % typ at 120 Hz
- Ripple Current: 12 mA max
- Dimensions: Size 4.0 x 5.5 mm
- Polarity: Negative terminal marked with semicircle or bar
- Soldering Profile: Preheat minimum 150°C, peak at 217°C, controlled ramp rates.
- Pressure Relief: Vent developed for internal pressure release
- RoHS & REACH compliant
- Storage and handling precautions outlined for durability and safety
Buy the Wurth Elektronik Series Capacitor: 3.3 UF 16V - 865250340001
Order the Wurth Elektronik aluminum electrolytic capacitor with 3.3 UF capacity, 16V rated voltage, and -40°C to +85°C operating range online today. This high-quality capacitor offers a load life of 2000 hours at 85°C and 16V, making it ideal for your electronics requiring stable performance and durability. Featuring a pressure relief vent for safety, it complies with RoHS and REACH standards. Ensure your circuit's reliability by purchasing this essential component directly online—easy, fast, and guaranteed authentic.
Buy Wurth Elektronik 865250340001 aluminum electrolytic capacitor now and experience unmatched reliability and performance in your electronic designs.
