WAGO 231365001000 Straight Solder Pin Header
The WAGO 231-365/001-000 header is a versatile component designed for secure and reliable connections in a variety of industrial applications. Its 5-pole configuration and 5.08mm pin spacing make it compatible with numerous systems. Constructed with a durable PA 6.6 insulating material and featuring electrolytic copper contacts with tin plating, this header ensures excellent conductivity and long-term performance. It is rated for voltages up to 320V and currents up to 12A, and meets various international standards including IEC/EN 60664-1. The header's closed end design provides added protection and safety. It is ideal for use in control cabinets, automation systems, and other electrical equipment.
WAGO 231365001000 Straight Solder Pin Header Specifications:
- Product Group: Multi Conn. System
- Weight: 2.09 g
- Color: orange
- Pole Count: 5
- Height: 12 mm
- Height_in: 0.472 in
- Width: 28.6 mm
- Width_in: 1.126 in
- Depth: 8.4 mm
- Depth_in: 0.331 in
- Pin Spacing From: 5.08 mm
- Pin Spacing From_in: 0.2 in
- Rating Based On: IEC/EN 60664-1
- Overvoltage Category EN I: III
- Pollution Degree: 2
- Measured Voltage EN: 320 V
- Measured Shock Voltage: 4 kV
- Current Intensity EN: 12 A
- Overvoltage Category EN II: II
- Current Intensity EN_2: 12 A
- Overvoltage Category EN III: III
- Degree of Pollution_2: 3
- Rated Voltage EN: 320 V
- Rated Surge Voltage: 4 kV
- Nominal Current: 12 A
- Solder Pin Length: 5 mm
- Solder Pin Width A: 1.2 mm
- Solder Pin Width B: 1.2 mm
- Diameter of Drilled Hole: 1.7 mm
- Tolerance of Drilled Hole Diameter: 0.1 mm
- Material Group: I
- Insulating Material: PA 6.6
- Temperature Stability: -60 °C to +100 °C
- Flammability Category UL94: V0
- Contact Material: Electrolytic copper (Ecu)
- Contact Plating: tin-plated
- Admission Office: ABS
- Approval No.: 04-HG469925/1-PDA
- Voltage_V: 400
- Current_A: 12
- Cross Section mm²: 0.8-2.5
- Approval No. BV: 11915/A0
- Voltage_V_BV: 400
- Current_A_BV: 16
- Cross Section mm²_BV: 2.5
- CCA Approval: 5764
- CCA Voltage: 250
- CCA Current: 16
- CCA Cross Section: 1.2x,21
- CSA Approval: 154112-1466354
- CSA Voltage: 300
- CSA Current: 15
- GL Approval: 17296-00HH
- GL Voltage: 400
- GL Current: 12
- GL Cross Section: 0.8-2.5
- KEMA Approval: 2083746.02
- KEMA Voltage: 250
- KEMA Current: 16
- KEMA Cross Section: 1.2x,21
- KR Approval: HMB05880-EL003
- KR Voltage: 250/400
- KR Current: 12/16
- KR Cross Section: 2.5
- LR Approval: 96/20035
- LR Voltage: 400
- LR Current: 12
- LR Cross Section: 0.8-2.5
- RMR Approval: 11130002
- RMR Voltage: 400
- RMR Current: 12
- RMR Cross Section: 0.8-2.5
- UR Approval: E45171
- UR Voltage: 600
- UR Current: 15
- UR Approval 2: E45172
- UR Voltage 2: 300/150/300
- UR Current 2: 15/15/10
