WAGO 231622 22-pole Connector
The WAGO 231-622 is a versatile 22-pole male connector within the MCS – MULTI CONNECTION SYSTEM. It provides a universal connection solution for all conductor types, facilitating easy cable pre-assembly and on-unit wiring through its innovative CAGE CLAMP actuation. This connector is ideal for wire-to-wire and board-to-wire connections in various industrial applications, offering a secure and reliable connection. It is designed with safety in mind, ensuring that header pins are not live when unmated, and is suitable for applications requiring robust electrical performance and ease of use.
WAGO 231622 22-pole Connector Specifications:
- Color: gray
- Conductor Size: 0.08 … 2.5 mm² / 28 … 12 AWG
- Pin Spacing: 5 mm
- Pole No.: 22
- Rated Voltage (III/3): 320 V
- Rated Surge Voltage (III/3): 4 kV
- Rated Current: 12 A
- Material: Polyamide 66 (PA66)
- Flammability Class: V0
- Weight: 32.6 g
- Operating Temperature: -60 … +100 °C
- Connection Technology: CAGE CLAMP®
- Contact Material: Electrolytic copper (E) Cu
- Contact Plating: tin-plated
