WAGO 231635019000 5-pole Connector
The WAGO 231-635/019-000 is a versatile 5-pole male connector suitable for wire-to-wire and board-to-wire connections. Its CAGE CLAMP actuation allows for easy cable pre-assembly and on-unit wiring. It is designed without breaking capacity for compliance with DIN EN 61984 and is available with snap-in mounting feet or flanges. This connector is ideal for various industrial applications requiring reliable and efficient connections.
Authorized Distributors
Source:Master Electronics
Part No:231-635/019-000
Stock:135
Inv Date:06-04-2026
Price: Unit price: $6.99
Buy/RFQ:
Source:Onlinecomponents.com
Part No:231-635/019-000
Stock:135
Inv Date:06-04-2026
Price: Unit price: $6.99
Buy/RFQ:
WAGO 231635019000 5-pole Connector Specifications:
- Rated voltage (III / 3): 320 V
- Rated impulse voltage (III / 3): 4 kV
- Rated voltage (III / 2): 320 V
- Rated impulse voltage (III / 2): 4 kV
- Rated voltage (II / 2): 630 V
- Rated impulse voltage (II / 2): 4 kV
- Rated current: 12 A
- Rated voltage UL (Use Group B): 300 V
- Rated current UL (Use Group B): 15 A
- Rated voltage UL (Use Group D): 300 V
- Rated current UL (Use Group D): 10 A
- Rated voltage per UL 1977 (factory wiring only): 600 V
- Rated current per UL 1977 (factory wiring only): 15 A
- Rated voltage CSA (Use Group B): 300 V
- Rated current CSA (Use Group B): 15 A
- Rated voltage CSA (Use Group D): 300 V
- Rated current CSA (Use Group D): 10 A
- Connection technology: CAGE CLAMP®
- Solid conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
- Fine-stranded conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
- Fine-stranded conductor with ferrule with plastic collar: 0.25 … 1.5 mm²
- Fine-stranded conductor with ferrule without plastic collar: 0.25 … 2.5 mm²
- Strip length: 8 … 9 mm / 0.31 … 0.35 inch
- No. of poles: 5
- Total number of connection points: 5
- Total number of potentials: 5
- Pin spacing: 5.08 mm / 0.2 inch
- Width: 40.2 mm / 1.583 inch
- Height: 14.3 mm / 0.563 inch
- Depth: 27.5 mm / 1.083 inch
- Mounting type: Mounting flange
- Contact type (pluggable connector): Male connector/plug
- Material: Polyamide 66 (PA 66)
- Flammability class per UL94: V0
