WAGO 232134005000 4-pole Female Connector
The WAGO 232-134/005-000 is a 4-pole female connector specifically engineered for use with rail-mount terminal blocks utilizing the CAGE CLAMP connection system. These connectors provide a pluggable, live output with enhanced safety features, including touch-proof contacts when unmated and coding fingers for secure connections. They are suitable for a variety of industrial applications requiring reliable and safe power distribution within rail-mounted systems. The connector's design allows for front-entry wiring and is constructed with durable materials like polyamide 66 and tin-plated copper alloy, ensuring long-term performance and reliability.
WAGO 232134005000 4-pole Female Connector Specifications:
- Pin Spacing: 5 mm
- Number of Poles: 4
- Total Number of Potentials: 4
- Rated Voltage (III / 3): 320 V
- Rated Impulse Voltage (III / 3): 4 kV
- Rated Voltage (III / 2): 320 V
- Rated Voltage (II / 2): 630 V
- Rated Impulse Voltage (II / 2): 4 kV
- Rated Current: 12 A
- Rated Voltage UL (Use Group B): 300 V
- Rated Current UL (Use Group B): 15 A
- Rated Voltage UL (Use Group D): 300 V
- Rated Current UL (Use Group D): 10 A
- Rated Voltage per UL 1977 (factory wiring only): 600 V
- Rated Current per UL 1977 (factory wiring only): 15 A
- Rated Voltage CSA (Use Group B): 300 V
- Rated Current CSA (Use Group B): 15 A
- Rated Voltage CSA (Use Group D): 300 V
- Rated Current CSA (Use Group D): 10 A
- Number of Connection Types: 1
- Number of Levels: 1
- Width: 21.5 mm
- Height: 32.75 mm
- Height from the Surface: 18.25 mm
- Depth: 11.6 mm
- Contact Type: Female connector/socket
- Connector Connection Type: for front-entry wiring terminal block
- Mismating Protection: No
- Steckrichtung zur Reihenklemme: 90 °
- Color: gray
- Insulating Material: Polyamide 66 (PA 66)
- Flammability Class per UL94: V0
- Contact Material: Copper alloy
- Contact Plating: tin-plated
- Fire Load: 0.077 MJ
- Weight: 4.3 g
- Limit Temperature Range: -60 … +85 °C
- Product Group: 3 (Multi Conn. System)
- Packaging Type: BOX
- Country of Origin: DE
- GTIN: 4044918569552
- Customs Tariff No.: 85366990990
