WAGO 7131107 14-pole Female Connector
The WAGO 713-1107 is a versatile 14-pole female connector designed for a wide range of conductor types. Its unique, compact, double-row design allows for high-density wire-to-board connections, making it ideal for applications with limited space. The connector incorporates a centered strain relief plate that acts as both a conductor anchor and a convenient handle for connection and disconnection. The 100% mismating protection ensures reliable connections, while the CAGE CLAMP® connection technology simplifies installation and maintenance. This connector is suitable for various industrial applications requiring robust and efficient electrical connections.
WAGO 7131107 14-pole Female Connector Specifications:
- pole_no: 14
- conductor_size: 1.5 mm²
- pin_spacing: 3.5 mm
- rated_voltage_iii3: 80 V
- rated_surge_voltage_iii3: 2.5 kV
- rated_voltage_iii2: 160 V
- rated_surge_voltage_iii2: 2.5 kV
- rated_voltage_ii2: 250 V
- rated_surge_voltage_ii2: 2.5 kV
- rated_current: 10 A
- solid_conductor_size: 0.08 … 1.5 mm² / 28 … 16 AWG
- fine_stranded_conductor_size: 0.08 … 1.5 mm² / 28 … 16 AWG
- fine_stranded_conductor_ferrule_size: 0.25 … 1 mm²
- strip_length: 6 … 7 mm / 0.24 … 0.28 inch
- material_group: II
- insulation_material: Glass fiber-reinforced polyamide (PA66 GF)
- flammability_class_ul94: V0
- weight: 7.3 g
- limit_temperature_range: -60 … +100 °C
- packaging_type: BOX
- country_of_origin: PL
- gtin: 4045454664824
- customs_tariff_number: 85366990990
